Honeywell Technologies Piezoresistive Pressure Sensor Through Hole 8 DIP SSC DRRV015PDAA5 SSCDRRV015PDAA5

Honeywell SSCDRRV015PDAA5 is a high-precision piezoresistive pressure sensor designed for through-hole mounting on PCBs, featuring an 8-pin DIP package and dual radial barbed ports for fluid connection. It operates over a supply voltage range of 3.3V to 5V and measures pressures from sub-atmospheric (-15 psi) to low positive pressures (up to 103 kPa), making it suitable for compact instrumentation and monitoring applications. The sensor provides an electrical output proportional to applied pressure with an accuracy of ±0.25%, supporting precise measurement tasks.

The device offers a robust operating temperature range of -40°C to 85°C combined with a maximum overload pressure of 413 kPa to reduce risk from pressure spikes. Its compact size, with a length of 10 mm and height of 13.75 mm, allows integration into small electronic assemblies. The dual radial barbed pressure transducer ports allow easy attachment of flexible tubing, simplifying fluid interface.

This pressure sensor is ideal for a variety of industrial and commercial applications including medical device manifold pressure monitoring, laboratory gas flow and low-pressure testing, HVAC control, leak detection systems, and portable battery-powered instrumentation. Its 8-pin DIP configuration facilitates easy insertion and soldering on PCBs, making it suitable for process control prototypes and other electronic designs requiring through-hole mounting.

Operates from 3.3V to 5V supply voltage levels. Accuracy of ±0.25% supports precise pressure measurement. Pressure measurement range from -15 psi to 103 kPa maximum operating pressure. Dual radial barbed ports designed for simple tubings fitment.

Wide temperature range from -40°C to 85°C for diverse environments. Maximum overload pressure of 413 kPa safeguards sensor integrity from spikes. Compact 8-pin DIP package size facilitates through-hole PCB mounting. Applicable in medical, laboratory, HVAC, and portable instrument fields.

This sensor belongs to Honeywell's SSC series and does not carry specific automotive or international certifications, making it a versatile choice for general industrial use. For more advanced sensing solutions browse EnvMart's extensive Pressure Sensor IC catalog to find additional options tailored to your precise technical requirements.
