Honeywell Technologies Piezoresistive Pressure Sensor Through Hole 8-DIP Package 3.3V-5V ±0.25% Accuracy SSCDANN030PAAA5
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 206 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | SSCDANN030PAAA5 |
| Sensor Type | Piezoresistive Pressure Sensor |
| Mount Type | Through Hole |
| Series | SSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Single Axial Barbed |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 0psi |
| Maximum Overload Pressure | 413kPa |
Key Features
- Measures absolute pressure up to 206 kPa with 413 kPa overload protection.
- Operates with supply voltage range from 3.3V to 5V suitable for low-voltage systems.
- Compact 8-pin DIP package enables easy PCB mounting in instrument panels.
- Single axial barbed port allows direct hose connection for fluid pressure sampling.
- Supports a wide operating temperature range from -40°C to 85°C for varied environments.
- Designed for pneumatic control loop monitoring and data acquisition modules.
- Offers robust operation in temperature-varied applications and test rigs.
- SSC series sensor designed for industrial, instrumentation, and control applications.
Product Description
Honeywell SSCDANN030PAAA5 is a SSC Series piezoresistive pressure sensor specifically designed for low-voltage instrument and control applications requiring precise absolute pressure measurement. It features a through-hole 8-pin DIP package ensuring secure and straightforward mounting on conventional PCBs.
The sensor measures pressures from 0 psi up to a maximum operating pressure of 206 kPa and withstands overload pressures up to 413 kPa, protecting the device from pressure spikes. It incorporates a single axial barbed port for easy connection to compatible tubing, simplifying fluid interfacing in pneumatic systems and test rigs.
Operating voltage ranges from a minimum of 3.3V to 5V, making it compatible with various low-voltage instrumentation and data acquisition modules. Its accuracy is ±0.25%, providing reliable measurements for sensitive control loops.
The operating temperature range spans from -40°C to 85°C allowing deployment in environments with varied temperature conditions, suitable for industrial, laboratory, and manufacturing settings.
This sensor device supports applications including pneumatic control loop monitoring, compact instrumentation panels, fluid pressure sampling, and low-voltage data acquisition systems where both precision and durability are essential.
Measures absolute pressures up to 206 kPa with 413 kPa overload tolerance. Supply voltage range 3.3V to 5V supports various low-voltage systems. 8-pin through-hole DIP package for easy PCB installation. Single axial barbed port enables straightforward fluid hose attachment.
Wide temperature operating range of -40°C to 85°C ensures versatile use. Offers ±0.25% accuracy ideal for pneumatic control and instrumentation. Compact design suitable for industrial, lab, HVAC, and manufacturing use. Set contains 1 Pc Honeywell SSCDANN030PAAA5 piezoresistive pressure sensor in 8-DIP package.
Explore more Pressure Sensor ICs and industrial measurement solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 206 kPa, with an overload protection of up to 413 kPa.
It operates within a supply voltage range of 3.3V to 5V, making it suitable for low-voltage systems.
This sensor has an accuracy of ±0.25%, providing reliable measurements for various applications.
The operating temperature range spans from -40°C to 85°C, allowing it to function in varied environmental conditions.
It incorporates a single axial barbed port for easy connection to compatible tubing, facilitating fluid pressure sampling.
The dimensions are 10mm in length and 13.75mm in height, suitable for compact installations.
This model features a through-hole mount type, ensuring secure and straightforward installation on PCBs.
It is designed for pneumatic control loop monitoring, fluid pressure sampling, and low-voltage data acquisition systems.
The sensor has a pin count of 8, compatible with standard DIP configurations.
The minimum operating pressure for this model is 0 psi, allowing it to measure absolute pressures starting from this point.
The country of origin for this product is India.
