onsemi AC/DC Input Optocoupler, Surface Mount, 8-Pin PDIP Package HCPL3700

Free Delivery in India | Lowest Global Shipping Charges

onsemi AC/DC Input Optocoupler, Surface Mount, 8-Pin PDIP Package HCPL3700

Name: onsemi AC/DC Input Optocoupler, Surface Mount, 8-Pin PDIP Package HCPL3700
Brand: onsemi
SKU: 412162
Price: 6.34 USD
Availability: InStock



Category Optocoupler Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Model	HCPL3700
Packaging	Tube
Mount Type	Surface
Series	HCPL
Maximum Operating Temperature	85°C
Package Type	PDIP
Minimum Operating Temperature	-40°C
Maximum input current	4.4mA
Number Of Channels	1
Standards/Approvals	EN, DIN, UL
Maximum Forward Voltage	0.65V
Number of Pins	8
Input Current Type	AC/DC
Typical Rise Time	45μs
Typical Fall Time	0.5μs
Broadcom HCPL-3700-000E AC/DC Input Optocoupler, Through Hole, 8-Pin PDIPBrand	Broadcom

Key Features

Supports AC and DC input current types for versatile applications.
Features a single channel with an 8-pin PDIP package type.
Maximum forward voltage is 0.65 volts ensuring efficient operation.
Typical rise time of 45 microseconds and fall time of 0.5 microseconds for fast switching.
Capable of withstanding isolation voltage up to 2.5kVrms for enhanced protection.
Operating temperature range from minus 40 to 85 degrees Celsius for reliability in harsh conditions.
Packaged in tubes suitable for insertion into machinery and production lines.
Includes logic output functionality for direct interfacing with control logic.

Product Description

onsemi HCPL3700 AC/DC Input Optocoupler is a surface-mount device designed for industrial and electronic control applications. It features a transistor output and supports both AC and DC input currents, making it suitable for relay contact monitoring and other industrial control systems.

With 8 pins arranged in a PDIP package, the device ensures ease of installation and robustness in circuit design. The optocoupler offers a maximum forward voltage of 0.65V and can handle input currents up to 4.4mA. Its typical rise and fall times of 45μs and 0.5μs respectively, allow for responsive switching suited to a range of industrial automation functions.

The unit withstands isolation voltages as high as 2.5kVrms, providing reliable electrical isolation between input and output circuits. Engineered for durability, it operates effectively within a temperature range from -40°C to +85°C.

Supports AC/DC input current types allowing flexibility in various circuit environments. Single channel configuration simplifies design requirements for monitoring systems. Surface mount PDIP 8-pin package for standard industry compatibility.

High isolation voltage rating ensures safety and signal integrity. Typical switching times suited for industrial control applications requiring rapid response. Logic output facilitates easy integration with digital control logic.

Reliable operation over wide temperature range for harsh industrial use. Packaged in tubes to facilitate efficient assembly and production line use. This optocoupler is ideal for use in industrial automation, HVAC systems, and manufacturing controls where reliable isolation and interface are critical.

Browse the Electronics Components > Optocoupler category on EnvMart for more high-quality optoelectronic components and Optocouplers.
