KEMET Polypropylene Capacitor 180nF 5% Tolerance 1.25kV DC 600V AC Through Hole R75RR318050H4J

Free Delivery in India | Lowest Global Shipping Charges

KEMET Polypropylene Capacitor 180nF 5% Tolerance 1.25kV DC 600V AC Through Hole R75RR318050H4J

Name: KEMET Polypropylene Capacitor 180nF 5% Tolerance 1.25kV DC 600V AC Through Hole R75RR318050H4J
Brand: KEMET
SKU: 411913
Price: 2.14 USD
Availability: InStock



Category Capacitors Brand KEMET Condition New

Specifications

Country of Origin	China
Brand	KEMET
Height	20mm
Length	32mm
Model	R75RR318050H4J
Packaging	Tape & Reel
Width	11mm
Mount Type	Through Hole
Series	R75
Maximum Operating Temperature	105°C
Tolerance	5 %
Capacitance	180nF
Minimum Operating Temperature	-55°C
Dissipation Factor	0.05%
Lead Length	25mm
Standards/Approvals	RoHS, IEC 60286-2
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	600V ac
Rated DC Voltage	1.25kV dc
Lead Pitch	27.5mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200
Equivalent Series Resistance ESR	6.2mΩ

Key Features

Capacitance of 180nF ensures precise energy storage in circuits.
5% tolerance allows reliable performance under design specifications.
Rated for 1.25kV DC and 600V AC operation for demanding applications.
Through hole design enables secure mounting and electrical connection.
Constructed with plastic case ensuring solvent resistance and self-extinguishing properties.
Compliant with RoHS and IEC 60286-2 standards for quality and safety.
Suitable for resonant circuits, silicon controlled rectifiers, and high frequency medium to high current applications.
Leads made of tinned wire with a pitch of 27.5mm and length of 25mm.

Product Description

KEMET R75RR318050H4J polypropylene capacitor delivers 180nF capacitance with a 5% tolerance, suitable for high voltage applications at 1.25kV DC and 600V AC. This through hole mount capacitor is encapsulated in a robust plastic case that is solvent resistant and self-extinguishing, ensuring durability and reliability in harsh environments.

The capacitor is designed specifically for use in resonant circuits, silicon controlled rectifiers, and high frequency medium to high current scenarios, making it ideal for industrial, electronic manufacturing, and laboratory instrumentation use cases. Its radial leads consist of tinned wire providing secure electrical connections with a lead pitch of 27.5mm and a lead length of 25mm.

Operating reliably between temperatures of -55°C and 105°C, this R75 series capacitor features a low dissipation factor of 0.05% and an equivalent series resistance (ESR) of 6.2mΩ, which together promote energy efficiency and minimal heat generation. It is compliant with RoHS and IEC 60286-2 standards, reflecting adherence to international quality and safety requirements.

The capacitor's dimensions are 32mm in length, 11mm in width, and 20mm in height, with lead diameter of 0.8mm. Its plastic case and thermosetting resin encapsulation contribute to its robust protection against environmental and electrical stresses. Country of Origin is China.

Capacitance: 180nF with 5% tolerance. Rated DC voltage of 1.25kV and AC voltage of 600V. Plastic casing with self-extinguishing properties. Radial leads with 27.5mm lead pitch and 25mm lead length. Operating temperature range -55°C to 105°C.

Low ESR of 6.2mΩ and dissipation factor of 0.05%. Complies with RoHS and IEC60286-2 standards. Application includes resonant circuits and high frequency current usage.

Widely used in electronics manufacturing, industrial equipment, and laboratory test setups, this capacitor provides high voltage and current tolerance along with structural reliability. Explore EnvMart categories for similar film Capacitors and electronic components to find the right fit for your technical needs.
