TDK-Lambda DC/DC Converter, 3.3V DC Output, 800mA, 18V Input, Through Hole DIP Package, 3W, CC3-1203SF-E
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK-Lambda |
| Efficiency | 0.74% |
| Length | 26.16mm |
| Model | CC3-1203SF-E |
| Depth | 16.6mm |
| Gross Weight | 4.5g |
| Width | 22.8mm |
| Mount Type | Through Hole |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 18V |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 9V dc |
| Number of Pins | 7 |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 800mA |
| Isolation Voltage | 500V |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Compact and efficient design suitable for industrial and telecommunications equipment.
- Input voltage range from 9V DC to 18V DC supporting various power sources.
- Maximum output power of 3 watts with 74% efficiency for reliable operation.
- Operating temperature range from -40°C to +85°C ensures durability under harsh conditions.
- Isolation voltage of 500V providing safety and noise reduction between input and output.
- Small footprint with dimensions 26.16mm length, 22.8mm width, and 16.6mm depth.
- Single output configuration with ±3% voltage adjustment capability.
- Package type is Dual Inline Package (DIP) with 7 pins for easy PCB mounting.
Product Description
TDK-Lambda CC3-1203SF-E is a DC/DC converter designed to convert 18V DC input to a regulated 3.3V DC output at 800mA current with maximum power output of 3 watts. This through hole DIP package device offers a compact footprint ideal for space-constrained electronic assemblies.
The unit supports an input voltage range from a minimum of 9V DC up to 18V DC, and provides single output voltage with an adjustment range of ±3%. It has an isolation voltage of 500V for electrical safety and noise isolation, critical for industrial, telecommunications, and consumer electronics applications requiring clean power conversion and protection.
Operating effectively across a temperature range from -40°C to +85°C, this model is suited for rigorous environments. The converter achieves 74% efficiency, optimizing power usage for reduced thermal stress.
The package is through hole with 7 pins in a DIP configuration, facilitating easy installation on printed circuit boards. The physical dimensions are 26.16mm in length, 22.8mm in width, and 16.6mm in depth, with a lightweight of 4.5 grams, making it convenient for compact designs.
This product complies with RoHS environmental standards and is manufactured in Japan, assuring quality and reliability. Applications range across industrial automation, telecommunications, instrumentation, and other electronic systems needing DC voltage conversion.
Compact and efficient DC/DC converter design. Wide input voltage range from 9V to 18V DC. Single output voltage of 3.3V DC at 800mA current. Through hole DIP package for easy PCB mounting. High isolation voltage of 500V for noise and safety.
Operating temperature from -40°C to +85°C for harsh environments. RoHS compliant and Japanese origin product. Explore more DC/DC Converters and power solutions on EnvMart for your industrial and commercial application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 9V DC to 18V DC.
This unit has a maximum output power of 3 watts.
It achieves an efficiency of 74%.
The dimensions are 26.16mm in length, 22.8mm in width, and 16.6mm in depth.
The isolation voltage is 500V, providing safety and noise reduction between input and output.
It operates effectively across a temperature range from -40°C to +85°C.
This model provides a single output configuration.
The output voltage is 3.3V DC with a current of 800mA.
It uses a through hole mounting type with a Dual Inline Package (DIP) configuration.
The gross weight of this converter is 4.5 grams.
Yes, it complies with RoHS environmental standards.
This product is manufactured in Japan.
