TRACOPOWER THM 3WI DC/DC Converter, 5V DC Output, 600 mA, 9V DC Max Input, 4.5V Min Input, 3W Power, DIP-24 PCB THM 3-0511WI
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THM 3WI DC/DC Converter, 5V dc/ 600 mA |
| Brand | TRACOPOWER |
| Efficiency | 84.5% |
| Length | 31.8mm |
| Model | THM 3-0511WI |
| Depth | 10.2mm |
| Mount Type | PCB |
| Series | THM 3WI |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP-24 |
| Minimum Operating Temperature | -40°C |
| MTBF | 6400000h |
| Number of outputs | 1 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 9V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 24 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 600mA |
| Isolation Voltage | 5kV ac |
| Ultra wide 4 | 1 input voltage |
Key Features
- High efficiency DC/DC converter designed for reliable power conversion.
- Wide input voltage range supports 4.5V to 9V DC supply.
- Single output of 5V DC with a maximum current of 600 mA.
- Compact DIP-24 plastic package suitable for PCB mounting.
- Supports extended operating temperature from -40°C to 100°C.
- Reliable I/O isolation voltage rated at 5 kV AC.
- High mean time between failure (MTBF) of 6,400,000 hours ensures long operational life.
- Input EMI filter compliant with EN55022 class A for noise suppression.
Product Description
TRACOPOWER THM 3-0511WI is a 3W DC/DC converter that provides a regulated isolated output suitable for industrial and medical applications. It operates from a wide 4:1 input voltage range of 4.5V to 9V DC, delivering a 5V DC output at 600 mA. The unit comes in a space-saving DIP-24 plastic package designed for PCB mounting.
With an extended operating temperature from -40°C to 100°C, the converter supports harsh environments, making it ideal for transportation systems, industrial control equipment, and precise measurement instruments. It features high efficiency of up to 87%, minimizing power loss and heat generation.
The product offers reinforced I/O isolation rated at 5,000 VAC rms, supporting 250V working voltage and meeting medical-grade safety requirements including 2 x MOPP (Means Of Patient Protection). Additionally, it includes an internal EMI filter complying with EN55022 class A, ensuring low electromagnetic interference.
High efficiency regulator with up to 87% efficiency. Wide 4:1 input voltage range from 4.5V to 9V. Strong isolation voltage rated at 5kV AC rms for safe operation. Supports medical safety with 2 x MOPP certification. Low leakage current under 2 μA enhances safety.
Complies with EN55022 Class A EMI filter standards. Robust operation in temperature extremes from -40°C to +100°C. Compact DIP-24 package enables dense PCB layouts. Mean Time Between Failure (MTBF) of 6,400,000 hours guarantees reliability.
Typical applications include medical, industrial control, transportation and IGBT driver circuits.
This DC/DC Converter from TRACOPOWER is designed for engineers and developers requiring a reliable, efficient, and isolated power module with broad input ranges and safety certifications. It is delivered in a tube for easy pick and place assembly onto PCBs.
Explore more high-quality voltage converters in the Electronics & Electricals section on EnvMart's platform.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The THM 3-0511WI provides a regulated output voltage of 5V DC with a maximum output current of 600 mA.
It operates within a wide input voltage range of 4.5V to 9V DC.
The maximum output power of this model is 3W.
This unit has a length of 31.8 mm and a depth of 10.2 mm, packaged in a DIP-24 format.
It features a reinforced isolation voltage rated at 5 kV AC.
The THM 3-0511WI can operate in temperatures ranging from -40°C to 100°C.
It has an efficiency rating of up to 87%.
This model is designed for PCB mounting.
It is suitable for industrial control, medical applications, transportation systems, and precise measurement instruments.
It meets medical safety requirements, including 2 x MOPP (Means Of Patient Protection).
The MTBF for the THM 3-0511WI is 6,400,000 hours.
Yes, it includes an internal EMI filter that complies with EN55022 Class A standards for noise suppression.
