TRACOPOWER DC/DC Converter THM 6-4815WI, 6W, 24V DC Output, 18V to 75V DC Input, PCB Mount, DIP-24 Package, 90°C Max Temp
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THM 6WI DC/DC Converter, 24V dc/ 250 mA |
| Brand | TRACOPOWER |
| Efficiency | 88% |
| Length | 31.8mm |
| Model | THM 6-4815WI |
| Depth | 10.2mm |
| Mount Type | PCB |
| Series | THM 6WI |
| Maximum Operating Temperature | 90°C |
| Package Type | DIP-24 |
| Minimum Operating Temperature | -40°C |
| MTBF | 4700000h |
| Number of outputs | 1 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 75V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 8 |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 250mA |
| Isolation Voltage | 5kV ac |
| Input Ratio | 4:1 |
| Input Ratio4 | 1 |
| Ultra wide 4 | 1 input voltage |
Key Features
- This converter delivers a stable 24V DC output voltage at 250 mA output current.
- It is designed for PCB mounting with a DIP-24 package and measures 31.8mm in length and 10.2mm in depth.
- The unit features high efficiency of up to 88%, enabling reliable and energy-efficient operation.
- Operating temperature ranges from -40°C to 90°C, suitable for harsh industrial environments.
- It provides reinforced I/O isolation rated 5kV AC for safe and reliable electrical separation.
- Ideal for applications in medical, transportation, industrial control, measurement and IGBT driver systems.
- Complies with medical safety requirements for Means Of Patient Protection (MOPP).
- The input filter meets EN55022 Class A EMI standards to reduce interference.
Product Description
The TRACOPOWER THM 6-4815WI DC/DC Converter is a high-efficiency, regulated isolated converter designed for demanding industrial and medical applications. With a compact DIP-24 plastic package intended for PCB mounting, it supports a wide input voltage range from 18V to 75V DC, delivering a stable 24V DC output at 250 mA and a maximum output power of 6W.
This converter operates efficiently up to 88% and endures a broad operating temperature range from -40°C up to 90°C, making it ideal for harsh environments such as transportation systems, industrial control equipment, measurement devices, and IGBT driver applications.
Its reinforced input/output isolation voltage of 5kV AC ensures strong electrical separation and safety, meeting medical safety standards including Means Of Patient Protection (MOPP). The in-built EMI filter complies with EN55022 Class A to minimize electromagnetic interference, guaranteeing reliable performance in sensitive electronic systems.
The unit features 8 pins and an input voltage ratio of 4:1, supported by a package depth of 10.2mm and length of 31.8mm. It does not carry specific approvals but adheres to ANSI/AAMI ES 60601-1:2005/(R)2012 and IEC/EN 60601-1 3rd edition standards relevant to medical equipment safety.
Manufactured in Taiwan, this TRACOPOWER converter ensures durability backed by an MTBF of 4.7 million hours. The THM 6WI series offers a reliable and compact power solution for critical power conversion needs in multiple industrial sectors.
This DC/DC converter delivers a steady output voltage of 24V DC at 250 mA output current. Operates across a wide input voltage range of 18V to 75V DC with 4:1 input ratio. Features reinforced 5kV AC isolation and complies with medical safety MOPP requirements.
High efficiency of 88% and low leakage current ensure energy-saving operation. Compact DIP-24 plastic package suitable for PCB mounting with dimensions 31.8mm x 10.2mm. Extended operating temperature range from -40°C to 90°C supports harsh environments.
Input EMI filter meets EN55022 Class A for reduced electromagnetic interference. Ideal for transportation, industrial control, measurement, and medical applications. Manufactured in Taiwan with an MTBF of 4,700,000 hours for superior reliability.
Explore more high-quality DC/DC Converters and power supplies in the Electronics & Electricals category on EnvMart for industrial and medical applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model delivers a stable output voltage of 24V DC with an output current of 250 mA.
It accepts a wide input voltage range from 18V to 75V DC, supporting an input ratio of 4:1.
The maximum output power of this unit is 6W.
The unit measures 31.8 mm in length and 10.2 mm in depth.
It can operate at a maximum temperature of 90°C.
It features a reinforced isolation voltage rating of 5kV AC.
This converter has an efficiency rating of up to 88%.
It is suitable for applications in medical, transportation, industrial control, measurement, and IGBT driver systems.
It operates within an extended temperature range from -40°C to 90°C, making it suitable for harsh environments.
It complies with medical safety standards including Means Of Patient Protection (MOPP) and adheres to ANSI/AAMI ES 60601-1:2005/(R)2012 and IEC/EN 60601-1 3rd edition standards.
The THM 6-4815WI has one output channel.
The Mean Time Between Failures (MTBF) for this model is 4.7 million hours.
