TE Connectivity Toggle Switch, Panel Mount, On-Off-On, DPDT, Solder Terminal, 28V DC, 125V AC A203P3ZQ04
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Length | 0.5in |
| Model | A203P3ZQ04 |
| Width | 0.45in |
| Mount Type | Panel |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -30°C |
| Terminal type | Solder |
| Standards/Approvals | RoHS |
| Switch Operation | On-Off-On |
| Actuator Length | 12.32mm |
| Contact DC Voltage | 28V dc |
| Switch Contact Current | 5A |
| Mechanical Life | 6000Cycles |
| Contact AC Voltage | 125V ac |
Key Features
- Designed for panel mounting with epoxy sealed terminals for durability.
- Features dual pole double throw (DPDT) contact configuration.
- Supports 5A contact current at 28V DC and 125V AC rating.
- Operating temperature range from -30°C to 85°C for wide environmental adaptability.
- Actuator length of 12.32mm and mechanical life of 6000 cycles.
- Compact size with length 0.5in and width 0.45in for versatile installation.
- Constructed with stainless steel frame and brass tin plated solder support for longevity.
- Compliant with RoHS standards ensuring environmental safety.
Product Description
TE Connectivity A203P3ZQ04 Toggle Switch is a high-quality panel mount switch featuring an On-Off-On operation with DPDT (Double Pole Double Throw) contact configuration. Rated for 5A contact current with 28V DC and 125V AC voltage ratings, this switch is ideal for precise control applications in industrial, electrical, automation, and control panel environments.
The toggle switch includes epoxy sealed terminals providing dependable electrical insulation and protection against environmental factors. Its robust stainless steel frame combined with brass tin-plated solder terminals ensures longevity and reliable performance under demanding mechanical cycling, rated for up to 6000 cycles.
With an actuator length of 12.32mm and physical dimensions of 0.5 inch length by 0.45 inch width, the switch fits standard panel mount cutouts with ease, facilitating convenient integration into various electronic and electrical assemblies.
Designed to operate reliably between temperatures of -30 degrees Celsius and 85 degrees Celsius, the switch suits a wide range of operating environments including industrial automation, manufacturing controls, HVAC systems, and other electrical control applications.
Compliance with RoHS standards guarantees reduced environmental impact by minimizing hazardous substances in its materials. Panel mount design with epoxy sealed terminals for enhanced durability. DPDT contact configuration allows complex switching arrangements.
Electrical ratings: 5A current at 28V DC and 125V AC voltage. Mechanical life expectancy up to 6000 switching cycles. Compact size ensuring compatibility with various panel systems.
This toggle switch is an essential component for applications requiring reliable manual electrical control with a compact form factor. Suitable for use in electrical panels, industrial automation systems, manufacturing lines, and other commercial electrical control devices.
Explore the full range of Toggle Switches and electrical components at EnvMart for comprehensive solutions tailored to your industrial and electrical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a dual pole double throw (DPDT) contact configuration, allowing for complex switching arrangements.
It is rated for 28V DC and 125V AC, supporting a contact current of up to 5A.
The switch operates reliably within a temperature range of -30°C to 85°C, making it suitable for various environments.
It has a length of 0.5 inches and a width of 0.45 inches, with an actuator length of 12.32mm.
The mechanical life of this toggle switch is rated for up to 6000 cycles, ensuring longevity in operation.
It features solder terminals that are epoxy sealed for enhanced durability and electrical insulation.
Yes, it is compliant with RoHS standards, which ensures reduced environmental impact by minimizing hazardous substances.
This model is designed for panel mounting, facilitating convenient integration into various electronic and electrical assemblies.
It is suitable for use in industrial automation, manufacturing controls, HVAC systems, and other electrical control applications.
The switch is constructed with a stainless steel frame and brass tin-plated solder support, ensuring reliable performance.
The maximum contact current for this toggle switch is 5A, making it suitable for various electrical control tasks.
The toggle switch is manufactured in India, reflecting its origin.
