Schneider Electric Power Relay with 48V AC Coil, 12A Switching Current, DPDT Contact Configuration RXM2AB1E7

Schneider Electric RXM2AB1E7 power relay is a Harmony RXM miniature plug-in relay designed for industrial automation, electrical enclosures, and machine control applications. It features a coil voltage rating of 48V AC and a switching current capability of 12A with double pole double throw (DPDT) contacts.

This relay offers a space-saving design with compact dimensions of 47.7mm width, 27mm height, and 21mm length, making it ideal for use in electrical panels where space is limited. Its silver alloy contacts ensure reliable conductivity and endurance under demanding operational conditions.

Operational temperature range from -40°C to 55°C allows deployment in environments with significant temperature variation. The coil has a power rating of 1.2W and resistance of 710 ohms contributing to efficient energy use.

The RXM2AB1E7 incorporates useful features such as a one-step lockable test button and a mechanical indicator enabling operators to easily verify the relay status without dismantling. Its IP40 rated transparent cover allows visual inspection to monitor switching.

Designed for compatibility with RXZE plug-in sockets, it can be secured against vibrations using optional plastic or metal clamps. Protection modules and marking legends are available to complement installation requirements.

This relay meets international standards including CSA and CE, assuring quality and compliance for industrial electrical systems. It is a green premium product suitable for use in complex automation systems alongside programmable logic controllers (PLCs).

Miniature plug-in power relay with 48V AC coil and DPDT contact configuration. 12A switching current supports high-rated industrial loads. Compact dimensions enable flexible mounting and space-saving. Test button and mechanical status indicator facilitate maintenance.

IP40 protection with transparent cover for safe operation monitoring. Compatible with RXZE sockets and optional vibration clamps. Silver alloy contacts for durability and conductivity. Meets CSA and CE international standards.

Suitable for industrial, electrical automation, HVAC, and manufacturing control applications. This versatile relay enhances machine reliability and permits precise control in electrical enclosures. Browse related Schneider Electric Power Relays at EnvMart for comprehensive automation solutions.
