Allegro Microsystems Current Sensor 8-Pin SOIC, 3-3.6V Supply, ±20mV Offset Voltage, 80kHz Bandwidth ACS722LLCTR-05AB-T

Allegro Microsystems ACS722LLCTR-05AB-T is a surface-mount current sensor integrated circuit packaged in an 8-pin SOIC form factor. It operates with a supply voltage from 3 to 3.6 volts and offers an offset voltage accuracy of ±20 mV, enabling precise current measurement over a broad temperature range of -40°C to 150°C. Featuring an 80 kHz bandwidth, this sensor IC is suitable for a variety of industrial, laboratory, and electrical current sensing applications requiring high speed and accuracy.

The device utilizes flip-chip technology combined with Hall effect principles, providing up to 3000 Vrms galvanic isolation, ensuring electrical safety and signal integrity in demanding manufacturing and industrial environments. It supports integrated sensing of currents up to 50 A, making it applicable for power management, motor control, and energy metering systems.

Its compact SOIC package measures 4.9 mm in length and 1.5 mm in height, designed for surface mounting to support high-density circuit board layouts. The ACS722 series by Allegro Microsystems has proven performance in automotive and commercial power electronics, although this specific model is not rated for automotive standards.

Provides high accuracy current sensing with ±20 mV offset voltage. Wide operating temperature range from -40°C to 150°C. Supports supply voltages between 3 V and 3.6 V. Compact 8-pin SOIC surface-mount package, 4.9 mm by 1.5 mm dimensions.

80 kHz bandwidth suitable for dynamic current measurements. Includes 3000 Vrms galvanic isolation for safety. Reliable flip-chip technology manufacturing process. Complies with RoHS environmental standards.

This Current Sensor IC is well suited for use in industrial tools, electrical measurement instruments, HVAC equipment, and various automated control systems. Its precision and high isolation make it ideal for integration into complex electronic assemblies where current monitoring is critical.
