Eaton xPole PLSM Miniature Circuit Breaker, 1-Pole, 63A, Type C, 48 V dc, 10 kA Breaking Capacity 242212 PLSM-C63-MW

Free Delivery in India | Lowest Global Shipping Charges

Eaton xPole PLSM Miniature Circuit Breaker, 1-Pole, 63A, Type C, 48 V dc, 10 kA Breaking Capacity 242212 PLSM-C63-MW

Name: Eaton xPole PLSM Miniature Circuit Breaker, 1-Pole, 63A, Type C, 48 V dc, 10 kA Breaking Capacity 242212 PLSM-C63-MW
Brand: Eaton
SKU: 382644
Price: 41.66 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Eaton Condition New

Specifications

Country of Origin	India
Range	xPole
Brand	Eaton
Model	242212 PLSM-C63-MW
Depth	75mm
IP Rating	IP20
Width	80mm
Mount Type	DIN Rail
Current Rating	63A
Series	PLSM
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	IEC, EN 60898-1
Rated DC Voltage	48V dc
Tripping Characteristics	Type C
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous
1 pole type C MCB,10kA 63ABrand	Hager

Key Features

This miniature circuit breaker ensures reliable protection against overcurrent in residential and commercial electrical systems.
Equipped with a toggle switch reset actuator and instantaneous break time for fast response.
Designed for DIN rail mounting with a 75mm depth and 80mm width, featuring IP20 protection.
Complies with IEC and EN 60898-1 standards, guaranteeing safety and performance.
Includes a contact position indicator with red-green color for clear status visibility.
The 3-position DIN rail clip allows secure terminal connection and easy removal from busbar systems.
Provides rated breaking capacity of 10 kA, suitable for demanding electrical installations.

Product Description

Eaton 242212 PLSM-C63-MW Miniature Circuit Breaker is a high-quality 1-pole MCB rated for 63A current and designed for 48 V dc applications. It features Type C tripping characteristics, making it ideal for protecting electrical circuits from overload and short circuits in both residential and commercial settings.

The device is designed for DIN rail mounting with compact dimensions of 75mm depth and 80mm width and an IP20 protection rating. It incorporates a toggle switch reset actuator and provides instantaneous breaking to quickly interrupt fault currents. A red-green contact position indicator clearly shows the device status for operational safety.

Certified to IEC and EN 60898-1 standards, the PLSM series meets insulation coordination requirements, including secure isolation with a ≥ 4 mm distance between contacts. The 3-position DIN rail clip enables easy installation and removal from existing busbar systems.

With a rated breaking capacity of 10 kA, this MCB provides robust protection suitable for a variety of industrial, commercial, and residential applications including electrical panels, control systems, and distribution boards.

Reliable overcurrent protection for DC circuits rated at 48 V. Instantaneous break time ensures quick fault clearing. Toggle switch allows easy manual operation and reset. Compact and secure DIN rail mounting with clips.

Compliance with international safety standards enhances trust and safety. Clear contact position indicator for operational status. High breaking capacity of 10 kA for demanding electrical conditions.

This Eaton xPole PLSM Miniature Circuit Breaker is an essential component for ensuring safe and reliable electrical distribution in industrial, commercial, and residential installations. Explore more Eaton electrical products and circuit breakers with EnvMart for premium quality and reliability.
