Carlo Gavazzi RA 24 Series Solid State Relay, 25 A Load Current, Panel Mount, 280V AC Load, 280V AC/DC Control RA2425HA06
Specifications
| Country of Origin | Malta |
|---|---|
| Brand | Carlo Gavazzi |
| Height | 29mm |
| Length | 57.8mm |
| Model | RA2425HA06 |
| Width | 44.5mm |
| Mount Type | Panel |
| Output type | Thyristor |
| Series | RA 24 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -20°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 25A |
| Standards/Approvals | CE, EAC |
| Maximum Load Voltage | 280V ac |
| Minimum Load Voltage | 24V ac |
| Minimum Control Voltage | 90V ac/dc |
| Maximum Control Voltage | 280V ac/dc |
| Off State Leakage Current | 3mA |
Key Features
- Designed for zero cross switching functionality to reduce electrical noise and wear.
- Compact size with dimensions 57.8mm length, 44.5mm width, and 29mm height for easy panel installation.
- Suitable for resistive and inductive AC loads to ensure versatile industrial use.
- Equipped with screw terminal type and SPST contact configuration for reliable electrical connections.
- Supports control voltages ranging from 90V AC/DC to 280V AC/DC for flexible control system integration.
- Operates safely within a temperature range from -20°C to 70°C ensuring durability in harsh environments.
- Utilizes direct copper bonding (DCB) technology for improved thermal management and reliability.
- LED status indication provides clear operational feedback for maintenance and monitoring.
Product Description
The Carlo Gavazzi RA2425HA06 is part of the RA 24 Series of Solid State Relays, engineered for demanding industrial control applications requiring high reliability and compact design. This panel-mounted relay is rated for a maximum load current of 25 amperes and a maximum load voltage of 280 volts AC, making it ideal for controlling various resistive and inductive AC loads.
This SSR employs zero cross switching technology, which minimizes electromagnetic interference and prolongs component life by switching at zero voltage crossing points. The relay features a single-pole single-throw (SPST) contact configuration with screw terminals, ensuring secure and straightforward wiring.
Designed with direct copper bonding (DCB) technology, the device offers efficient thermal dissipation, enhancing performance and longevity in continuous operation. The built-in LED status indicator simplifies troubleshooting and operational monitoring.
The RA2425HA06 supports a control voltage range from 90 volts AC/DC up to 280 volts AC/DC, providing flexibility in various automation and control systems. It operates reliably within ambient temperatures from -20°C to 70°C, suitable for harsh industrial environments.
With a compact footprint measuring 57.8mm by 44.5mm by 29mm, installation in control panels is facilitated without requiring excessive space. Zero cross switching reduces electrical noise and component wear. Compact panel mount form factor for easy integration.
Suitable for resistive and inductive AC load control. Screw terminal connections with SPST contacts. Wide AC/DC control voltage range enhances versatility. Direct copper bonding for superior thermal management. LED status indicator for operational monitoring.
Operates within -20°C to 70°C ambient temperature.
These features make the Carlo Gavazzi RA series relays a reliable choice for industrial automation, manufacturing, HVAC control panels, and electrical signaling applications. Manufactured in Malta, these products meet CE and EAC standards, ensuring compliance with international quality and safety regulations.
Explore further relays and automation components in the Electronics & Electricals category on EnvMart for your control system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 25 amperes.
This model supports a control voltage range from 90 volts AC/DC to 280 volts AC/DC.
The dimensions are 57.8mm in length, 44.5mm in width, and 29mm in height.
It features a single-pole single-throw (SPST) contact configuration.
It operates reliably within a temperature range from -20°C to 70°C.
This model is equipped with screw terminal connections.
The maximum load voltage is 280 volts AC.
It employs zero cross switching technology to minimize electromagnetic interference and prolong component life.
This product meets CE and EAC standards, ensuring compliance with international quality and safety regulations.
It is suitable for controlling various resistive and inductive AC loads.
The built-in LED status indicator provides clear operational feedback for maintenance and monitoring.
The output type of this relay is thyristor.
