Carlo Gavazzi RP1 Series Solid State Relay, 4 A Load Current, PCB Mount, 60 V DC Load Voltage, 32 V DC Control RP1D060D4

Carlo Gavazzi RP1D060D4 solid state relay is an analog switching device designed for industrial and automation applications requiring efficient DC load switching. It operates based on the phase angle control principle, enabling smooth control of resistive and slightly inductive loads with a maximum load current of 4 A and load voltage up to 60 V dc. The device design includes an integral snubber network that protects against voltage spikes and enhances device longevity.

This relay is engineered for PCB mounting with compact form factor dimensions of 43 mm in length and 25.4 mm height. It features plug-in terminals facilitating easy and secure connections. The device supports a maximum control voltage of 32 V dc and a minimum control voltage of 4.25 V dc, providing precise control inputs. Its operational temperature range from -20°C to 80°C makes it suitable for a broad range of industrial environments.

With an off state leakage current of only 0.01 mA, it ensures minimum power loss when inactive, improving overall system efficiency. Compliance with UL and cUL approvals guarantees adherence to international safety standards. Originating from China, this relay is widely applicable in automation systems, industrial equipment, and control circuits requiring reliable solid state switching.

Capable of switching resistive and slightly inductive loads using phase angle control principle. Features an integral snubber network for protection. Rated for maximum control voltage of 32 V dc and minimum control voltage of 4.25 V dc.

Operates reliably from -20°C up to 80°C ambient temperature. Low off-state leakage current of 0.01 mA enhances energy efficiency. Compact dimensions of 43 mm length and 25.4 mm height for easy PCB integration. Plug-in terminal type for simplified installation.

Compliant with UL/cUL standards ensuring safety and quality.

This solid state relay is ideal for use in industrial automation, manufacturing control systems, and electrical assemblies where precise DC load switching and durability are essential. Explore our extensive selection of Solid State Relays and contactors on EnvMart for industrial and electrical applications.
