Carlo Gavazzi RAM 1A Series Solid State Relay, Panel Mount, 125 A Load Current, 660 V AC Load Voltage, 32 V DC RAM1A60D125

Carlo Gavazzi RAM1A60D125 is a high-performance Solid State Relay designed for reliable and efficient switching of high current AC loads in industrial and automation applications. It features a panel mount design with screw terminals, ensuring secure and safe connections. This relay accommodates a maximum load current of 125 amperes and a maximum load voltage of 660 volts AC, making it suitable for demanding power control tasks.

The device operates with a DC control voltage range of 4 to 32 volts, allowing flexible integration into various control systems. The solid-state design utilizes a thyristor output offering noiseless switching and increased lifespan over mechanical relays. It incorporates zero cross switching, minimizing electrical noise and reducing wear during switching cycles. Integrated snubber networks add protection against voltage transients.

Compactly sized at 44.8 mm length, 44.5 mm width, and 28.8 mm height, it fits neatly into panels and control cabinets. The relay is rated for operation in environments ranging from -40°C to +80°C, providing robust performance in harsh industrial settings. LED status indication facilitates monitoring of relay operation for maintenance and troubleshooting.

This solid state relay is ideal for switching resistive loads and controlling motors, enhancing reliability in HVAC systems, manufacturing equipment, water treatment plants, and other industrial automation scenarios. With its integral heatsink and touch-safe IP20 cover, it ensures safety and efficient heat dissipation during operation.

Originating from China, the Carlo Gavazzi RAM1A60D125 caters to professionals requiring a durable and efficient AC load switching solution. It represents advanced technology in relay control, combining high load capacity, robust protection features, and compact design.

Designed for panel mounting with screw terminal connections. Maximum load current rating of 125 amperes ensures robust switching performance. Supports load voltage up to 660 volts alternating current. Control voltage range is 4 V to 32 V DC for versatile control applications.

Employs zero cross switching function for reduced electrical noise and increased reliability. Equipped with a thyristor output type for solid-state switching. Compact dimensions: 44.8 mm length, 44.5 mm width, and 28.8 mm height.

Operating temperature range from -40°C up to 80°C for industrial environments. Features LED status indication and integral snubber network to protect against voltage spikes. Suitable for resistive loads and motor control in industrial automation systems.
