Eaton xEffect Miniature Circuit Breaker, 2-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 278776 FAZ-D5/2

Free Delivery in India | Lowest Global Shipping Charges

Eaton xEffect Miniature Circuit Breaker, 2-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 278776 FAZ-D5/2

Name: Eaton xEffect Miniature Circuit Breaker, 2-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 278776 FAZ-D5/2
Brand: Eaton
SKU: 381418
Price: 117.51 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Eaton Condition New

Specifications

Country of Origin	India
Range	xEffect
Brand	Eaton
Model	278776 FAZ-D5/2
Depth	73mm
IP Rating	IP20
Width	85mm
Mount Type	DIN Rail
Current Rating	5A
Series	xEffect
Terminal type	Twin-Purpose Terminal
Breaking Capacity	10kA
Number of Poles	2
Rated AC Voltage	415V ac
Tripping Characteristics	Type D
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous

Key Features

Thermal-magnetic trip mechanism ensures dependable over-current protection.
Instantaneous break time protects circuits from short circuits.
Supports 2 poles with a current rating of 5 amperes.
Rated AC voltage of 415 volts suitable for heavy-duty applications.
Breaking capacity rated at 10 kA for robust circuit interruption.
Toggle switch reset actuator with trip-free design ensures safety.
Twin-purpose terminal type for versatile wiring connections.
IP20 rated enclosure protects against solid object intrusion.

Product Description

The Eaton 278776 FAZ-D5/2 xEffect Miniature Circuit Breaker is a high-quality two-pole device designed for effective overload and short circuit protection in industrial and commercial electrical installations. Rated for 5 amperes and 415V AC, this circuit breaker features a thermal-magnetic tripping mechanism providing reliable six-level protection with instantaneous break capabilities.

Designed for DIN rail mounting, it has compact dimensions of 85 mm in width and 73 mm in depth, allowing for easy integration in control panels. The toggle switch reset actuator can be sealed in the on or off position for additional security, and its trip-free design prevents the handle from being held in the on position to defeat the breaker.

This model supports twin-purpose terminals for flexible wiring and comes with an IP20 rating ensuring protection against solid foreign objects. The current-limiting design reduces let-through energy during fault conditions, preventing damage to downstream components.

Eaton's xEffect series is widely regarded for its reliability and safety in electrical distribution systems, perfectly suited for industrial, commercial, and HVAC applications requiring dependable supplementary protection.

Thermal-magnetic overcurrent protection with instantaneous trip. Rated for 5A current at 415V AC voltage. 10 kA breaking capacity suitable for industrial circuits. Toggle switch for manual reset and sealed positions. Compatible with DIN rail mounting systems.

Robust construction with IP20 ingress protection. Twin-purpose terminal enables flexible wiring options. Compact form factor ideal for panel installations. Enhanced safety with trip-free mechanism. Industrial-grade circuit breaker for control panels and electrical automation.

This Eaton Miniature Circuit Breaker is an essential component for protecting electrical equipment from overcurrents and short circuits, ensuring safety and reliability in electrical distribution systems. It is ideal for use in industrial automation, electrical panels, HVAC systems, and commercial installations.
