Wurth Elektronik WR-PHD Series Straight Through Hole Pin Header, 4 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded 61300421121

Wurth Elektronik 61300421121 WR-PHD Series straight through hole pin header is a high-quality connector designed for effective board-to-board interfacing in electronic applications. Featuring 4 contacts spaced at a 2.54 mm pitch across two rows, it facilitates reliable electrical connections in compact circuit board layouts.

This pin header is crafted with a polyamide housing rated UL94-V0, providing robust insulation and flame retardance. The contacts are made from a copper alloy with gold plating to guarantee excellent conductivity and corrosion resistance. Its unshrouded design allows easy access to pins for flexible PCB assembly tasks.

Mounting is through-hole type, with tail pins measuring 3 mm, ensuring secure soldering and mechanical stability. The product supports a maximum operating voltage of 250 V and current of 3 A, suitable for standard industrial and commercial electronic components.

Operational temperature range spans from -40°C to 105°C, catering to various environmental conditions. The 2 row and 2.54 mm row pitch provide precise alignment and compatibility with standard PCB layouts.

Manufactured in Taiwan, Province Of China, the WR-PHD series connector is a reliable choice for equipment in industrial, electronic manufacturing, and commercial sectors requiring sturdy, compact, and efficient pin headers.

Dual row 2.54 mm pitch unshrouded pin header for board-to-board connections. Four male contacts made from gold-plated copper alloy ensure reliable conductivity. Housing constructed from black UL94-V0 rated polyamide for durability and insulation.

Engineered for through-hole mounting with a tail pin length of 3 mm for secure soldering. Operates within a temperature range of -40°C to 105°C, supporting up to 250 V and 3 A current. Connector system designed for precise board-to-board application with straight orientation.

Compliant with no specific standards or approvals, manufactured in Taiwan, Province Of China. Explore more PCB headers and connectors from Wurth Elektronik and enhance your electronic components with reliable connectivity solutions available on EnvMart.
