Wurth Elektronik WR-PHD Series 2.54mm Pitch Right Angle Through Hole Pin Header Connector 12 Contacts 3A Current 61301221021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- Features polyamide black UL94-V0 PBT housing for excellent durability.
- Gold plated copper alloy contacts ensure reliable conductivity and corrosion resistance.
- Right angle orientation allows space-efficient PCB mounting.
- Rated for up to 250V voltage and operating temperatures from -40°C to 105°C.
- Contact tail pin length is 3 mm and mating pin length is 6 mm for secure solder connections.
- Unshrouded dual-row design facilitates easy board-to-board connection.
- Suitable for industrial electronics and power connector applications.
- Manufactured in Taiwan, Province Of China with high-quality standards.
Product Description
Wurth Elektronik 61301221021 WR-PHD Series right angle through hole pin header connector features a 2.54 mm pitch and a robust design with 12 male contacts arranged in 2 rows. It has an unshrouded configuration allowing straightforward connectivity for PCB applications.
This connector employs polyamide housing with black UL94-V0 PBT material, providing flame retardant properties and long-term durability. The copper alloy contacts are gold plated to guarantee excellent electrical conductivity and minimize oxidation, ideal for high-reliability environments.
Designed for industrial, manufacturing, electronic assembly, and power electronics use, it supports operating voltages up to 250V and a continuous current of 3 Amps. The connector withstands operating temperatures ranging from -40°C to 105°C, making it suitable for a wide range of environmental conditions.
The right angle orientation optimizes board space, while the 3 mm tail pin length and 6 mm mating pin length secure reliable solder joint connections. This component is well suited for board-to-board connection systems requiring durability and precision.
Durable polyamide black UL94-V0 PBT housing. Gold plated copper alloy contacts for superior conductivity. Right angle, through hole mount for space-efficient PCB layout. Unshrouded 2-row, 12 contact male connectors. Rated for 250V and 3A current operational use.
Operating temperature range from -40°C to 105°C. Tail pin length 3 mm and mating pin length 6 mm. Manufactured in Taiwan, Province Of China.
This PCB Pin Header connector is an integral component for electronics manufacturing, industrial automation, and power connector assemblies. It ensures reliable electrical connection in demanding usage scenarios.
Explore the full range of PCB headers and connectors by Wurth Elektronik on EnvMart for your next electronics project or production line.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header connector is 2.54 mm.
This model features 12 male contacts arranged in 2 rows.
It is rated for a maximum voltage of 250V.
The connector has a continuous current rating of 3 Amps.
The housing is made of polyamide with black UL94-V0 PBT, and the contacts are composed of gold plated copper alloy.
It can operate in temperatures ranging from -40°C to 105°C.
This connector uses a through hole mounting type.
The tail pin length is 3 mm, while the mating pin length is 6 mm.
This model features an unshrouded design, facilitating easy board-to-board connections.
It is suitable for use in industrial electronics, manufacturing, electronic assembly, and power connector applications.
This connector is manufactured in Taiwan, Province Of China.
It is designed for board-to-board connection systems.
