Wurth Elektronik WR-PHD Series 2.54mm Pitch Right Angle Through Hole Pin Header Connector 18 Contacts 1 Row 61301811021
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 18 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 6mm |
Key Features
- Features 2.54mm pitch for standard PCB mounting.
- Right angle orientation supports compact board layouts.
- Contains 18 male copper alloy contacts plated with gold.
- Constructed with durable polyamide housing (black UL94-V0 PBT insulator).
- Designed for through hole mount with solder termination.
- Operates between -40°C and 105°C for reliable performance.
- Tail pin length of 3mm and mating pin length of 6mm for secure connection.
- Unshrouded connector system, board-to-board type.
Product Description
Wurth Elektronik 61301811021 WR-PHD Series Right Angle Through Hole Pin Header Connector features an 18-contact, 1-row configuration with a 2.54mm pitch. This unshrouded, male pin header uses a polyamide black UL94-V0 PBT housing for high durability and safety.
The right angle orientation assists in efficient PCB designs where space saving is critical. Contacts are constructed from copper alloy with gold plating, ensuring excellent conductivity and corrosion resistance. Termination is via solder type for stable, long-lasting board connections.
Rated for 3 amperes and 250 volts, these connectors operate reliably in temperatures between -40°C and 105°C, suitable for a wide range of industrial, electronic, and manufacturing applications.
Tail pin length is 3mm and mating pin length is 6mm, designed for effective mechanical and electrical contact. The board-to-board connector system facilitates easy integration into electronic devices and assemblies.
This product is manufactured in Taiwan, Province Of China, providing consistent quality and compliance standards. The WR-PHD series is the preferred choice for high-performance PCB header applications requiring ruggedness and reliable connections.
Features 2.54mm pitch for standard PCB mounting. Right angle orientation supports compact board layouts. Contains 18 male copper alloy contacts plated with gold. Constructed with durable polyamide housing (black UL94-V0 PBT insulator).
Designed for through hole mount with solder termination. Operates between -40°C and 105°C for reliable performance. Voltage rating of 250V and current rating of 3A. Tail pin length of 3mm and mating pin length of 6mm for secure connection.
Unshrouded connector system, board-to-board type. Manufactured in Taiwan, Province Of China. Ideal for industrial electronics, manufacturing equipment, instrumentation, and electrical assembly applications. Explore more products in the PCB Headers category at EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header connector is 2.54mm, which is standard for PCB mounting.
This model features 18 male contacts arranged in a single row.
It operates reliably within a temperature range of -40°C to 105°C.
The voltage rating is 250V and the current rating is 3A.
The housing is made of polyamide, and the contacts are constructed from copper alloy with gold plating.
This connector is designed for solder termination, ensuring stable and long-lasting connections.
The tail pin length is 3mm, while the mating pin length is 6mm.
It utilizes a board-to-board connector system, which facilitates easy integration into electronic devices.
This connector is unshrouded, allowing for more compact PCB designs.
This product is manufactured in Taiwan, Province Of China.
It is suitable for a wide range of industrial, electronic, and manufacturing applications.
The orientation of this connector is right angle, which supports compact board layouts.
