Vishay Through Hole Slotted Optical Switch Phototransistor Output 24.5x6.3x10.8mm TCST2202

Vishay TCST2202 Through Hole Slotted Optical Switch features a phototransistor output designed for precise and reliable sensing in various industrial and electronic applications. Measuring 24.5 mm in length, 6.3 mm in width, and 10.8 mm in height, this miniature sensor integrates an infrared emitter and phototransistor aligned face-to-face within a leaded package that blocks visible light to enhance detection accuracy.

This slotted optical switch is ideal for applications such as optical switches, photo interrupters, counters, and encoders. It supports through-hole mounting with 4 pins and comes packaged in tubes facilitating easy insertion into machinery and PCB assembly.

Performance highlights include a typical rise time of 10 microseconds and fall time of 8 microseconds, providing rapid response to changes in the optical path. The device operates reliably within a broad temperature range from -55°C to 85°C, suitable for harsh environmental conditions. The slot width of 5 mm allows it to detect objects passing through the slot accurately. The emitter wavelength of 950 nm is optimized for infrared detection.

Production ensures compliance with the RoHS directive, making it an environmentally responsible choice. Made in the Philippines, Vishay maintains strict quality standards in manufacturing this slotted optical switch.

Industrial use cases include electronics manufacturing, automation controls, position sensing in machinery, and optical encoders. It is a compact sensor solution for integrating into electronic devices requiring object detection, interruption sensing, or positional feedback.

The device integrates infrared emitter and phototransistor face-to-face in a leaded package blocking visible light. Typical rise and fall times are 10μs and 8μs respectively for fast response. Slot width is 5 mm suitable for precise detection applications.

Designed for through hole mounting with 4 pins and packaged in tubes for easy handling. Operational temperature range spans from -55°C to 85°C for versatility. Emitter wavelength is 950 nm to work with infrared detection systems.

Typical output current under test is 2 mA providing stable signals. Meets RoHS standards ensuring compliance with environmental regulations. Manufactured in Philippines ensuring quality production standards. Browse EnvMart's comprehensive range of optical sensors and switches for advanced industrial control and automation needs.
