Phoenix Contact SMSTB 2.5/6-ST-5.08 Series Pluggable Terminal Block, 6-Contact, 5.08 mm Pitch, 320 V, 12 A 1826322

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact SMSTB 2.5/6-ST-5.08 Series Pluggable Terminal Block, 6-Contact, 5.08 mm Pitch, 320 V, 12 A 1826322

Name: Phoenix Contact SMSTB 2.5/6-ST-5.08 Series Pluggable Terminal Block, 6-Contact, 5.08 mm Pitch, 320 V, 12 A 1826322
Brand: PHOENIX CONTACT
SKU: 373762
Price: 20.22 USD
Availability: InStock



Category Pluggable Terminal Block Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Germany
Voltage	320V
Brand	Phoenix Contact
Colour	Green
Orientation	Straight
Current	12A
Length	30.48mm
Model	1826322
Depth	15.5mm
Width	25.6mm
Housing Material	Polyamide
Series	SMSTB 2.5/6-ST-5.08
Number of Rows	1
Pitch	5.08mm
Number of Contacts	6
Connector Gender	Female
Minimum Wire Size mm²	0.2mm²
Maximum Wire Size mm²	2.5mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	12AWG
Wire Connection Method	Screw Connection with Tension Sleeve
Optimized for tight installation situations	operation and conductor connection from one direction

Key Features

The terminal block utilizes a polyamide housing for durability and insulation.
It has a female connector design suitable for flexible wiring.
Supports wire sizes from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG) for versatile applications.
The connection method uses a screw connection with tension sleeve for secure contact.
Optimized for tight installation situations with operation and conductor connection from one direction.
Single row configuration with straight orientation ensures easy integration.
Compact dimensions of 30.48 mm length, 25.6 mm width, and 15.5 mm depth.
Ideal for industrial electronic connection and automation system applications.

Product Description

Phoenix Contact 1826322 SMSTB 2.5/6-ST-5.08 Series Pluggable Terminal Block delivers reliable and compact connectivity solutions for industrial and electronic applications. Designed with a 6-contact configuration and a pitch of 5.08 mm, this terminal block supports electrical loads up to 320 V and 12 A.

The unit features a robust polyamide housing that provides excellent mechanical and insulation properties. It incorporates a female connector with a screw connection including tension sleeve technology, ensuring stable and low-resistance electrical connections. The product supports a wire cross-section range from 0.2 mm² to 2.5 mm², corresponding to 24 AWG up to 12 AWG standards.

This terminal block’s single row, straight orientation layout optimizes space efficiency and facilitates installation in confined spaces. Its design allows operation and conductor connection from one direction, easing wiring procedures and maintenance. The compact size with a length of 30.48 mm, width of 25.6 mm, and depth of 15.5 mm makes it suitable for dense assemblies and control cabinets.

Manufactured in Germany, the SMSTB 2.5/6-ST-5.08 series complies with RoHS directives, contributing to environmentally sound applications. It is well-suited for use in industrial automation systems, power distribution, and other electrical control frameworks requiring dependable terminal connections.

The terminal block utilizes a polyamide housing for durability and insulation. It has a female connector design suitable for flexible wiring. Supports wire sizes from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG) for versatile applications.

The connection method uses a screw connection with tension sleeve for secure contact. Optimized for tight installation situations with operation and conductor connection from one direction. Single row configuration with straight orientation ensures easy integration.

Compact dimensions of 30.48 mm length, 25.6 mm width, and 15.5 mm depth. Ideal for industrial electronic connection and automation system applications. Discover extensive industrial and electrical connectivity solutions with Phoenix Contact products and browse the EnvMart catalog for more terminal blocks and connectors.
