TDK Wirewound Shielded Surface Mount Inductor, Ferrite Core, 15 μH ±10% Inductance, 15.3A Max DC Current, Package ERU20
Specifications
| Country of Origin | China |
|---|---|
| Brand | TDK |
| Height | 12.2mm |
| Length | 21.5mm |
| Model | ERU20 |
| Depth | 21mm |
| Packaging | Tape & Reel |
| Series | B82559A |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | RoHS |
| Package/Case | ERU20 |
| Maximum DC Current | 15.3A |
| Maximum DC Resistance | 4.9mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- This inductor features a magnetically shielded design for minimal electromagnetic interference.
- The ERU20 package size is compact with dimensions of 21.5 mm length, 12.2 mm height, and 21 mm depth.
- It has a maximum DC resistance of 4.9 milliohms ensuring low power loss.
- Certified to automotive standard AEC-Q200, suitable for automotive applications.
- Designed to operate in a temperature range from -40°C to 150°C.
- Inductance tolerance is ±10%, offering reliable performance.
- Core material is high-quality ferrite providing stable magnetic properties.
- Surface mount termination style allows easy PCB mounting.
Product Description
The TDK ERU20 wirewound shielded surface mount inductor is a high-performance passive electronic component designed for demanding applications requiring stable inductance and high current capacity. Featuring a ferrite core, this inductor offers an inductance of 15 μH with a tolerance of ±10% and supports a maximum DC current of 15.3 A, making it suitable for power conversion and filtering circuits.
This inductor's magnetically shielded construction minimizes electromagnetic interference, ensuring robust operation in compact electronic assemblies. The package conforms to the ERU20 size, with dimensions measuring 21.5 mm in length, 12.2 mm in height, and 21 mm in depth, making it compatible with automated surface mount assembly processes using tape and reel packaging.
Built for reliability, the component meets the automotive industry standard AEC-Q200, verifying its durability under harsh environmental conditions including a wide operating temperature range from -40°C to 150°C. The low maximum DC resistance of 4.9 mΩ reduces power losses during operation, enhancing efficiency in DC-DC converters, POL converters, VRM modules, and solar converters.
Additional practical benefits include the surface mount termination style optimized for modern PCB layouts, and compliance with RoHS standards ensuring environmentally safe manufacturing and disposal.
Magnetically shielded design for EMI reduction. Compact ERU20 surface mount package. High rated current capacity of 15.3 A. Low DC resistance of 4.9 mΩ minimizes power loss. Wide operating temperature range from -40°C to 150°C.
Meets automotive AEC-Q200 qualification standards. Reliable ferrite core construction. Compliant with RoHS environmental standards.
This surface mount inductor by TDK is ideal for industrial, automotive, and commercial electronics requiring high performance inductors in power management circuits. Explore the full range of TDK inductors for efficient design solutions in power electronics and signal filtering applications at EnvMart.
