Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 470 μH ±20 % 460 mA Idc DR74-471-R

Free Delivery in India | Lowest Global Shipping Charges

Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 470 μH ±20 % 460 mA Idc DR74-471-R

Name: Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 470 μH ±20 % 460 mA Idc DR74-471-R
Brand: Eaton
SKU: 367448
Price: 1.23 USD
Availability: InStock



Category Surface Mount Inductor Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	4.35mm
Length	7.6mm
Model	DR74-471-R
Depth	7.6mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	470μH
Standards/Approvals	RoHS
Package/Case	0704
Maximum DC Current	460mA
Pin Count	2
Maximum DC Resistance	1.74Ω
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

Magnetically shielded wirewound inductor for surface mount applications.
Ferrite core construction ensures high efficiency and thermal stability.
Maximum operating temperature up to 125°C for reliable performance.
Package type 0704 with 7.6 mm length and 4.35 mm height dimensions.
RoHS compliant with molded construction for durability.
Inductance tolerance of plus or minus 20 percent.
Maximum self-resonant frequency of 100 kHz suitable for noise filtering.
Designed for use in computers, portable devices, LCD panels, and DC-DC converters.

Product Description

Eaton DR74-471-R is a shielded wirewound surface mount inductor featuring a ferrite core with an inductance of 470 μH and a tolerance of ±20 %. It supports a maximum DC current of 460 mA and is designed to withstand operating temperatures up to 125°C. This inductor is housed in a 0704 package with a length of 7.6 mm, a height of 4.35 mm, and a depth of 7.6 mm.

The DR series inductors from Eaton are magnetically shielded drum core inductors optimized for high power density and efficiency. The ferrite core construction helps minimize electromagnetic interference, making it suitable for sensitive electronic circuits.

With a maximum DC resistance of 1.74 Ω and a maximum self-resonant frequency of 100 kHz, this wirewound inductor excels in noise filtering, acting as a choke in buck, boost, forward, and resonant converters. It is molded and RoHS compliant, with a surface mount termination style.

Typical applications include computers, DVD players, portable electronic devices, LCD panels, and various DC-DC power converter configurations in industrial and commercial electronic equipment.

Magnetically shielded wirewound construction for improved EMI performance. Ferrite core for high efficiency and thermal stability. Compact 0704 package dimensions suited for high-density PCB layouts. Operating temperature range from -40°C to 125°C ensures reliability in harsh environments.

RoHS compliant and molded for durability and easy surface mount placement. Maximum DC resistance of 1.74 Ω reduces power loss during operation. Self-resonant frequency of 100 kHz enhances filtering and noise suppression.

Pin count of 2 and surface mount termination style for automated assembly. Set contains 1 Pc Eaton DR74-471-R Wirewound Surface Mount Inductor.

Ideal for industrial, consumer electronics, computing, and power management applications. Explore more Surface Mount Inductors and related components at EnvMart for comprehensive product options and technical support.
