Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±20 % 2.47 A IDC, 0703 Package DR73-100-R

Free Delivery in India | Lowest Global Shipping Charges

Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±20 % 2.47 A IDC, 0703 Package DR73-100-R

Name: Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±20 % 2.47 A IDC, 0703 Package DR73-100-R
Brand: Eaton
SKU: 367437
Price: 0.99 USD
Availability: InStock



Category Surface Mount Inductor Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	3.55mm
Length	7.6mm
Model	DR73-100-R
Depth	7.6mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	10μH
Standards/Approvals	RoHS
Package/Case	0703
Maximum DC Current	2.47A
Pin Count	2
Maximum DC Resistance	65.6mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

The inductor features a 0703 surface mount package ensuring compact PCB integration.
It is constructed with a wirewound design on a ferrite core providing magnetic shielding for noise reduction.
Inductance tolerance is ±20 % suitable for general power filtering applications.
Maximum operating temperature of 125°C allows use in demanding industrial environments.
The device offers a maximum DC resistance of 65.6 milliohms minimizing power loss.
It supports a maximum self-resonant frequency of 100 kHz for stable high-frequency operation.
The product is RoHS compliant, molded and designed for surface mount termination with 2 pins.
Applications include power conversion, noise filtering, and use in DC-DC converters and portable electronics.

Product Description

The Eaton DR73-100-R shielded wirewound surface mount inductor with a ferrite core provides an inductance of 10 μH with a tolerance of ±20 %, suitable for industrial electronic applications requiring effective noise filtering and power management. Operating reliably at temperatures from -40°C to 125°C, this compact 0703 package component supports a maximum DC current of 2.47 A and has a maximum DC resistance of 65.6 mΩ, ensuring efficient energy transfer with minimal loss.

This inductor features a magnetically shielded wirewound construction on a ferrite core that reduces electromagnetic interference, making it ideal for use in computers, DVD players, LCD panels, and various DC-DC converters including buck, boost, forward, and resonant types. Its molded design and surface mount termination style facilitate easy PCB assembly within automated manufacturing processes.

The maximum self-resonant frequency of 100 kHz ensures stable operation in high-frequency circuits. Compliant with RoHS standards, Eaton’s DR series inductors are designed for demanding industrial, electronic, and manufacturing environments where reliable power conditioning is required.

The inductor is housed in a 0703 sized surface mount case measuring approximately 7.6 mm in length and 3.55 mm in height. Its two-pin termination style supports precise, secure electrical connections. The ferrite core contributes to effective magnetic shielding and enhanced efficiency.

The DR73-100-R model is part of Eaton's DR series, known for high power density and efficiency. Application domains include noise filtering, power supply modules, portable device electronics, and industrial automation. The device's compact reel packaging is optimized for production line insertion increasing manufacturing throughput.

Overall, the Eaton DR73-100-R inductor offers a robust and efficient solution for a wide range of surface mount electronic power and signal conditioning applications. Browse more premium Surface Mount Inductors and electrical components on EnvMart for trusted industrial-grade electronics parts and components.
