Eaton 0805 Shielded Surface Mount Inductor, Composite Iron Powder Core, 2.2 μH ±20% 14 A IDC HCP0805

Eaton HCP0805 0805 Shielded Surface Mount Inductor is designed for high current carrying capacity in compact SMD applications. Featuring a composite iron powder core and wirewound construction, it delivers an inductance of 2.2 μH with ±20% tolerance.

This inductor supports a maximum DC current of 14 Amps and a maximum operating temperature of 125°C, making it suitable for demanding industrial, automotive, and electronic applications. Its magnetically shielded design minimizes electromagnetic interference and core losses, enhancing overall efficiency.

The device comes in a standard 0805 SMD package with dimensions of 7.4 mm length, 7.7 mm depth, and 5 mm height. It is halogen free and fully RoHS compliant, meeting current environmental standards.

Typical applications for the Eaton HCP0805 series include voltage regulator modules (VRM), multi-phase regulators, desktop and server power systems, base station equipment, and notebook regulators. It is also well suited for point-of-load modules and battery power systems in data networking and storage environments.

This Surface Mount Inductor features a shielded design to reduce electromagnetic interference. Constructed with a wirewound coil on a composite iron powder core for efficient performance. Supports a maximum DC current of 14 Amps with a low DC resistance of 11.2 milliohms.

Operates reliably between -40°C and 125°C with a self-resonant frequency up to 2 MHz. Compliant with RoHS and halogen free, suitable for automotive and industrial use. Compact 0805 package size measuring 7.4 x 7.7 x 5 mm.

Applications include VRM, multi-phase regulators, desktop/server power, and point-of-load modules. Explore more high-quality inductors and power components in the Electronics & Electricals category at EnvMart for robust industrial and commercial applications.
