Eaton Wirewound Shielded Surface Mount Inductor with Ferrite Core 150 μH ±20 % 3.01 A Idc DR127-151-R

Eaton DR127-151-R shielded wirewound surface mount inductor featuring a ferrite core provides a nominal inductance of 150 μH with ±20 % tolerance and supports a maximum DC current of 3.01 A. This inductor is part of the DR series, designed for high power density and efficiency in power electronics applications.

The inductor is packaged in a 0127 surface mount case and supplied on a reel to facilitate automated PCB assembly processes. It operates reliably in temperatures ranging from -40°C to 125°C, making it suitable for industrial, computing, and consumer electronics environments.

Its magnetically shielded design minimizes electromagnetic interference, enhancing circuit performance in sensitive applications such as DC-DC converters, buck, boost, forward, and resonant converters, as well as noise filtering. The wirewound construction on a ferrite core ensures robust magnetic characteristics, while the low maximum DC resistance of 247 mΩ reduces energy loss and heat generation.

The compact dimensions of 12.5 mm length and depth with 8 mm height allow for space-saving designs in densely populated PCBs. The inductor is RoHS compliant, ensuring adherence to environmental regulations.

Magnetically shielded wirewound drum core construction. High efficiency and power density. Surface mount termination style for automated assembly. Suitable for computing devices, LCD panels, and portable electronics. Ideal for DC-DC power conversion and noise filtering applications.

This Eaton DR series inductor is manufactured in China and meets rigorous quality standards. It is ideal for industrial, laboratory, electronics manufacturing, and HVAC equipment where reliable inductive components are essential. Browse more inductors and surface mount components at EnvMart to find compatible parts for your project.
