Eaton Shielded Surface Mount Inductor with Ferrite Core 330 μH ±20% 1.22 A Idc DR125-331-R

Free Delivery in India | Lowest Global Shipping Charges

Eaton Shielded Surface Mount Inductor with Ferrite Core 330 μH ±20% 1.22 A Idc DR125-331-R

Name: Eaton Shielded Surface Mount Inductor with Ferrite Core 330 μH ±20% 1.22 A Idc DR125-331-R
Brand: Eaton
SKU: 367428
Price: 1.28 USD
Availability: InStock



Category Surface Mount Inductors Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Height	6mm
Length	12.5mm
Model	DR125-331-R
Depth	12.5mm
Packaging	Reel
Series	DR
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	330μH
Standards/Approvals	RoHS
Package/Case	0125
Maximum DC Current	1.22A
Pin Count	2
Maximum DC Resistance	482mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Wirewound

Key Features

This surface mount inductor features a ferrite core with magnetic shielding for enhanced performance.
It has an inductance tolerance of ±20% ensuring reliability in circuit designs.
The device operates within a temperature range of -40°C to 125°C for broad application use.
Maximum DC resistance is specified at 482 mΩ to optimize circuit efficiency.
Its compact dimensions measure 12.5 mm in length and 6 mm in height offering space-efficient PCB mounting.
The inductor is molded and wirewound, designed for surface mount terminations.
The maximum self-resonant frequency is 100 kHz suitable for various power electronics filtering applications.
Manufactured to RoHS standards with Country of Origin China.

Product Description

Eaton DR125-331-R is a shielded surface mount inductor featuring a ferrite core with a rated inductance of 330 μH and a ±20% tolerance. It supports a maximum DC current of 1.22 A, making it ideal for high-efficiency power and filtering applications.

This wirewound inductor is designed for surface mounting on PCBs with a compact footprint of 12.5 mm length by 6 mm height and a molded body for durability. It operates reliably within a temperature range of -40°C to 125°C, suitable for industrial, electronic components, power, and connector applications.

With a maximum DC resistance of 482 milli-ohms, this inductor ensures minimal power losses. The device operates with a maximum self-resonant frequency of 100 kHz, making it effective for noise filtering, DC-DC converters, buck, boost, forward, and resonant converters.

The product is RoHS compliant, ensuring environmental safety, and is manufactured in China under quality standards. Typical use cases include computers, DVD players, portable devices, LCD panels, and other consumer electronics requiring reliable inductive components.

This inductor features magnetic shielding for reduced electromagnetic interference. The 2-pin surface mount termination style enables easy mounting on circuit boards. It comes packaged on a reel making it suitable for automated assembly processes.

The DR series is known for high power density and efficiency in electronic applications. Core material is ferrite, specifically chosen for its magnetic properties. Its compact size aids in space-constrained electronic device designs.
