TE Connectivity Panel Mount Toggle Switch, On-On, 4PDT, Solder Terminal, 250 V ac, FT Ultraminiature Series 3-6437630-5

TE Connectivity 3-6437630-5 is a panel mount toggle switch from the FT Ultraminiature Series designed for robust and compact switching solutions in industrial and instrumentation applications. This On-On, 4PDT switch provides reliable control across multiple circuits with a solder terminal connection ideal for lasting electrical integrity. Rated for 6 A contact current and 250 V ac operating voltage, it suits light to medium duty equipment such as medical devices, automation panels, and instrumentation.

The switch features a chrome plated brass actuator with a length of 10.5 mm, ensuring durability and smooth operation within its compact form factor of 23 mm length, 14.8 mm width, and 10.5 mm height. Designed for panel mounting, it requires a panel cutout size of 6.2 mm for standardized installation. Its mechanical life of 50,000 cycles highlights dependable long-term usage, and RoHS compliance guarantees adherence to environmental and safety standards.

This toggle switch performs reliably in environmental conditions ranging from -20°C to +70°C, making it versatile for various industrial, laboratory, manufacturing, and automation settings. The FT Ultraminiature Series is valued for its balance of size and functionality, enabling efficient space utilization without compromising performance.

Applications include use in industrial control panels, instrumentation devices, medical equipment, and other scenarios where secure and precise switching is critical. The solder terminal design accommodates robust wiring practices, complementing assembly and maintenance practices in professional environments.

This toggle switch features a 4PDT contact configuration for versatile circuit control. The switch operates with an On-On action ensuring stable toggling between two circuit states. Solder-type terminals facilitate secure and durable wire connections.

It is built with a chrome plated brass actuator to withstand wear and environmental exposure. The switch is rated for a maximum contact current of 6 amperes and contact voltage of 250 V ac. Panel mounting is supported with a standard 6.2 mm panel cutout size for easy installation.

The compact dimensions measure 23 mm length, 14.8 mm width, and 10.5 mm height. The device complies with RoHS standards ensuring reduced hazardous substances in manufacturing. Mechanical life expectancy is rated at 50,000 cycles, promising durable operation.

Operating temperature range spans from -20°C to 70°C suitable for diverse environments.
