RS PRO Toggle Switch, PCB Mount, On-Off-On, SPDT, Through Hole Terminal, 28 V dc, 112 V ac 734-7132

RS PRO 734-7132 Toggle Switch is a miniature SPDT toggle switch designed for PCB mounting in electronic and electrical applications. It supports on-off-on switch operation with a through hole terminal type, providing robust and reliable switching performance for control circuits.

Capable of handling contact voltages of 28 V dc and 112 V ac at a maximum switch contact current of 5A, this switch is well-suited for industrial, automation, electrical, and HVAC applications. Its chrome plated brass actuator offers durability and smooth operation, with a length of 10.41 mm for ergonomic handling.

Designed to function reliably in harsh conditions, it operates within a wide temperature range of -30°C to 85°C and has a mechanical life rated for 40,000 cycles, making it suitable for frequent switching tasks in manufacturing and electronic equipment.

The switch features a compact form factor with a panel cutout size of 6.35 mm, facilitating installation into tight spaces and PCBs for embedded system designs.

Compliance with key international standards such as CE, CSA, RoHS, and UL ensures the switch meets quality, safety, and environmental regulations, making it ideal for global industrial and commercial deployment.

PCB mounting ensures stable and reliable installation in circuits. On-Off-On switch operation provides three stable positions for versatile control. SPDT contact configuration allows single pole double throw switching. Through hole terminal type facilitates easy soldering and connection.

Supports up to 5A switch contact current for moderate loads. Chrome plated brass actuator for enhanced durability. Wide operating temperature range from -30°C to 85°C. Compact panel cutout size of 6.35 mm suits small designs.

Mechanical life rated at 40,000 cycles ensures long-term reliability. Certified to CE, CSA, RoHS, and UL standards.

RS PRO Toggle Switches are designed to meet the demands of industrial automation, electronic control, consumer electronics, and HVAC sectors. Their compact size and robust mechanical lifespan make them a reliable choice for embedded control solutions.
