Murata Power Solutions 10 mH Leaded Inductor Radial Mount, Max SRF 200 kHz, Q 48, 600 mA Idc, 2294 mΩ Rdc, Series 1410606C
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 24.4mm |
| Brand | Murata Power Solutions |
| Operating Temperature | -40 → +85°C |
| Height | 23.3mm |
| Length | 32.4mm |
| Model | 1410606C |
| Depth | 31.3mm |
| Mount Type | Radial |
| Series | 1400 |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 10mH |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 715-6850Brand: Murata Power SolutionsManufacturers Part No.: 1410606C |
| Maximum DC Current | 600mA |
| Maximum DC Resistance | 2294mΩ |
| Inductance Tolerance | ±10% |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 200kHz |
| Minimum Quality Factor | 48 |
| Lead Pitch | 28.5mm |
| Lead Diameter | 0.54mm |
Key Features
- High saturation flux density material for high current capability.
- Max self-resonant frequency of 200 kHz ensuring effective high-frequency operation.
- Rated maximum DC current of 600 mA for robust performance.
- Inductance tolerance of ±10% for reliable circuit design.
- Compact radial mount form factor for PCB or chassis integration.
- Operating temperature range from -40°C to 85°C for versatile environments.
- Easy-strip pre-tinned enamelled copper leads for solder terminations.
- RoHS compliant and sourced from China.
Product Description
Murata Power Solutions model 1410606C is a 10 mH leaded inductor from the 1400 series, designed for power line applications including switching regulators, filters, and suppression circuits.
Constructed with high saturation flux density material, it supports high current operation with a maximum DC current rating of 600 mA and maximum DC resistance of 2294 mΩ. The inductor provides a quality factor (Q) of 48 and a maximum self-resonant frequency (SRF) of 200 kHz.
This radial mount component features easy-strip pre-tinned enamelled copper leads terminated by soldering, with a lead pitch of 28.5 mm and lead diameter of 0.54 mm. Its compact physical dimensions include a diameter of 24.4 mm, length of 32.4 mm, height of 23.3 mm, and a depth of 31.3 mm, suitable for PCB or chassis mounting using a non-magnetic fastener through the central hole.
It is qualified to operate across a wide temperature range from -40°C to 85°C and maintains an inductance tolerance of ±10%, providing stability under varying thermal conditions.
The product meets RoHS standards for environmental compliance and originates from China. This inductor is ideal for industrial electronics, power management systems, and commercial electronic device manufacturing, where reliable filtering and current handling are critical.
High saturation flux density material for high current capability. Max self-resonant frequency of 200 kHz ensuring effective high-frequency operation. Rated maximum DC current of 600 mA for robust performance. Inductance tolerance of ±10% for reliable circuit design.
Compact radial mount form factor for PCB or chassis integration. Operating temperature range from -40°C to 85°C for versatile environments. Easy-strip pre-tinned enamelled copper leads for solder terminations. Dimensions: 24.4 mm diameter, 32.4 mm length, 23.3 mm height.
RoHS compliant and sourced from China. Explore Murata Power Solutions inductors in EnvMart for more options suited for power electronics and industrial applications.
Explore more products in our Passive Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 10 mH, providing reliable performance for various applications.
It has a maximum DC current rating of 600 mA, suitable for high current applications.
The maximum self-resonant frequency (SRF) is 200 kHz, ensuring effective high-frequency operation.
The inductor has a diameter of 24.4 mm, a length of 32.4 mm, a height of 23.3 mm, and a depth of 31.3 mm.
It operates within a temperature range of -40°C to +85°C, making it versatile for various environments.
The inductance tolerance is ±10%, providing stability in circuit design.
This model features a radial mount design, suitable for PCB or chassis integration.
The quality factor (Q) of this inductor is 48, indicating its efficiency in energy storage.
It has a solder termination style, with easy-strip pre-tinned enamelled copper leads for soldering.
Yes, this inductor is RoHS compliant, ensuring it meets environmental standards.
The maximum DC resistance is 2294 mΩ, which is important for minimizing power loss.
This model is suitable for power line applications including switching regulators, filters, and suppression circuits.
