Bourns 6045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2 μH Semi Shielded ±30% 3.5 A SRN6045
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 4.5mm |
| Length | 6mm |
| Model | SRN6045 |
| Depth | 6mm |
| Packaging | Reel |
| Series | SRN6045 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 3.5A |
| Maximum DC Resistance | 25mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 35MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Semi Shielded |
| Automotive systems | Driver assistant, information, lighting, entertainment |
Key Features
- The inductance is 2.2 μH with a tolerance of ±30%.
- Maximum DC current rating is 3.5 A for reliable conduction.
- Features a ferrite core and semi shielded wire wound construction.
- Compact 6045 package with dimensions 6 mm length, 4.5 mm height, 6 mm depth.
- Operates between -40°C and 125°C with maximum DC resistance of 25 mΩ.
- Termination style is solder, suited for surface mount PCB applications.
- Maximum self-resonant frequency of 35 MHz and minimum quality factor of 15.
- RoHS compliant and moulded for durability and quality assurance.
Product Description
Bourns SRN6045 model 6045 shielded wirewound surface mount inductor with ferrite core is a semi shielded power inductor designed for surface mounting in compact electronic assemblies. The component provides an inductance of 2.2 μH with a tolerance of ±30% and a maximum DC current rating of 3.5 A, making it suitable for high-performance circuit applications.
The inductor houses a ferrite core surrounded by a wirewound construction that is semi shielded to reduce electromagnetic interference while maintaining excellent magnetic performance. The device is designed for operation at temperatures ranging from -40°C to 125°C, ensuring reliability in demanding environments.
Featuring a 6045 package case with precise dimensions of 6 mm length, 4.5 mm height, and 6 mm depth, the inductor’s termination uses solder for easy PCB integration. It operates with a maximum DC resistance of 25 mΩ and a maximum self-resonant frequency of 35 MHz, achieving a minimum quality factor of 15.
This product is RoHS compliant and moulded for robustness. The SRN6045 series inductors are supplied on reels, enhancing production efficiency in automated assembly lines. Ideal use cases include automotive electronics such as driver assistance systems, lighting, and entertainment modules, as well as DC-DC converters and power supply filtering.
The inductance value of 2.2 μH suits power management applications requiring compact inductors. The semi shielded design helps reduce electromagnetic interference in sensitive circuitry. A maximum DC current of 3.5 A enables handling higher power loads reliably.
Temperature range from -40°C to 125°C supports automotive and industrial operating conditions. Packaged on a reel for convenient automated placement on PCBs within manufacturing processes.
Bourns inductors are renowned for quality and reliability, making the SRN6045 a strong choice for electronic designers seeking durable surface mount power inductors with ferrite cores. Browse more inductors or surface mount components in the Electronics & Electricals category at EnvMart.
Explore more products in our Surface Mount Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of the SRN6045 inductor is 2.2 μH with a tolerance of ±30%.
This model has a maximum DC current rating of 3.5 A, allowing it to handle higher power loads reliably.
The dimensions of the 6045 package are 6 mm in length, 4.5 mm in height, and 6 mm in depth.
The maximum operating temperature for this inductor is 125°C, making it suitable for demanding environments.
The SRN6045 uses a ferrite core, which helps in achieving excellent magnetic performance.
The maximum self-resonant frequency of this inductor is 35 MHz.
The termination style of the SRN6045 is solder, which is suited for surface mount PCB applications.
The minimum quality factor for this model is 15, indicating its efficiency in energy storage.
The maximum DC resistance of the SRN6045 is 25 mΩ, which contributes to its efficient performance.
This inductor is typically used in automotive electronics such as driver assistance systems, lighting, and DC-DC converters.
The minimum operating temperature for this inductor is -40°C, allowing it to function in a wide range of environments.
Yes, the SRN6045 is RoHS compliant, ensuring it meets environmental standards.
