TE Connectivity Panel Mount Toggle Switch On-Off-On SPDT Solder Terminal 24 V dc 20 V ac 3-1825137-8
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Length | 0.50in |
| IP Rating | IP68S |
| Width | 0.27in |
| Mount Type | Panel |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Switch Configuration | (On)-Off-(On) |
| Minimum Operating Temperature | -30°C |
| Panel Cutout Size | 6.35 mm |
| Terminal type | Solder |
| Standards/Approvals | EN, RoHS, IEC, UL, cULus |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 710-9416Brand: TE ConnectivityManufacturers Part No.: 3-1825137-8 |
| Switch Operation | On-Off-On |
| Actuator Length | 10.41mm |
| Contact DC Voltage | 24V dc |
| Switch Contact Current | 400mA |
| Mechanical Life | 6000Cycles |
| Contact AC Voltage | 20V ac |
| Actuator Material | Nickel |
Key Features
- Features a robust panel mount design for secure fitting.
- Provides a single-pole double-throw (SPDT) contact configuration.
- Equipped with solder terminals for easy connection.
- Rated for 400mA contact current ensuring efficient performance.
- Constructed with nickel actuator material for durability.
- Supports an IP68S ingress protection rating for harsh environments.
- Operates in temperature ranges from -30°C to 85°C.
- Mechanical life expectancy up to 6000 cycles.
Product Description
TE Connectivity 3-1825137-8 panel mount toggle switch is designed for industrial and electronic applications requiring reliable control with On-Off-On switch operation. It features a single-pole double-throw (SPDT) contact configuration, making it suitable for switching circuits in automation, electrical panels, and consumer electronics.
The switch is mounted securely on panels with a precise 6.35 mm cutout size, ensuring easy installation. It has solder terminals designed for robust electrical connections and efficient current transfer rated at 400mA.
Constructed with a nickel actuator and epoxy-sealed terminals inside a stainless steel frame with brass tin-plated solder support, it offers excellent durability and resilience. The switch meets high environmental protection standards with an IP68S rating, suitable for harsh and humid conditions.
Operating temperature ranges from -30°C to 85°C make it usable in various industrial environments. Additionally, its mechanical lifespan of 6000 cycles ensures long-term reliability.
Panel mount design providing stable and secure placement. Single-pole double-throw switch configuration for versatile circuit control. Solder terminal connections for reliable electrical contact. IP68S ingress protection rating for water and dust resistance.
Wide temperature range operation from -30°C to 85°C. Durable nickel actuator and stainless steel frame construction. Mechanical life rated up to 6000 cycles for extensive use. Approved to multiple international standards including EN, IEC, UL, and cULus.
Compact dimensions with 0.50 inch length and 0.27 inch width.
This toggle switch is ideal for use in electrical control systems, manufacturing machinery, HVAC equipment, and automation solutions requiring precise manual switching. TE Connectivity’s commitment to quality ensures dependable performance across industrial applications.
Explore EnvMart’s comprehensive range of Toggle Switches and electrical components designed for industrial automation and electrical systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a single-pole double-throw (SPDT) contact configuration, suitable for versatile circuit control.
The maximum operating temperature for this toggle switch is 85°C.
It has an IP68S ingress protection rating, making it suitable for harsh and humid conditions.
The switch is rated for a contact current of 400mA, ensuring efficient performance.
This model has a length of 0.50 inches and a width of 0.27 inches.
It is equipped with solder terminals designed for robust electrical connections.
The mechanical life expectancy of this model is rated at 6000 cycles.
The required panel cutout size for this toggle switch is 6.35 mm.
This toggle switch is manufactured in India.
It is approved to multiple international standards including EN, RoHS, IEC, UL, and cULus.
The minimum operating temperature for this toggle switch is -30°C.
This toggle switch operates in an On-Off-On configuration, allowing for versatile control.
