Vishay 1-Element Uni-Directional Transient Voltage Suppressor 1500 W 2-Pin DO-214AB SMCJ36A-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ36A-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | SMCJ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AB (SMC) |
| Minimum Operating Temperature | -55°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 699-8118Brand: VishayManufacturers Part No.: SMCJ36A-E3/57TDistrelec Article No.: 304-36-159 |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 58.1V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 40V |
| Maximum Reverse Stand-off Voltage Vwm | 36V |
| Peak Pulse Power Dissipation Pppm | 1500W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 25.8A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Provides effective transient voltage suppression for protection of sensitive electronic components.
- Designed for high surge capability with peak pulse power dissipation of 1500 watts.
- Operating temperature range from -55°C to 150°C for reliable performance.
- Compact DO-214AB (SMC) surface mount package with 2-pin configuration.
- Clamping voltage of 58.1 V ensures minimal voltage overshoot during transients.
- Maximum reverse stand-off voltage rating of 36 V.
- Low leakage current of 1 microampere for energy efficiency.
- Complies with automotive standard AEC-Q101 for enhanced reliability.
Product Description
Vishay SMCJ36A-E3/57T transient voltage suppressor (TVS) diode is a high performance, 1-element, uni-directional device designed to safeguard electronic circuits against voltage transients induced by inductive load switching and lightning.
This surface mount device features a DO-214AB (SMC) package with 2 pins, enabling compact PCB layout and easy installation in modern electronics. The device withstands peak pulse power of 1500 watts under standard test conditions, providing robust surge protection.
Temperature operation range spans from -55°C to 150°C, ensuring stable operation under harsh environmental conditions common in industrial, automotive, and consumer electronics applications.
The device includes absolute maximum ratings with minimum breakdown voltage of 40 V and maximum reverse stand-off voltage of 36 V. It ensures clamping voltage at 58.1 V, limiting transient voltage peaks effectively to protect downstream components.
With peak pulse current capability of 25.8 A and a very low leakage current of 1 microampere, the SMCJ36A-E3/57T offers reliable electrical performance and energy efficiency. The diode meets automotive quality standards under AEC-Q101, making it suitable for transportation electronics.
Suitable applications include industrial power supplies, voltage transient suppression in control and communication equipment, and automotive electronic systems. This diode is engineered to protect sensitive semiconductors and discrete semiconductor devices from damage due to voltage spikes.
Provides effective transient voltage suppression for protection of sensitive electronic components. Designed for high surge capability with peak pulse power dissipation of 1500 watts. Operating temperature range from -55°C to 150°C for reliable performance.
Compact DO-214AB (SMC) surface mount package with 2-pin configuration. Clamping voltage of 58.1 V ensures minimal voltage overshoot during transients. Maximum reverse stand-off voltage rating of 36 V. Low leakage current of 1 microampere for energy efficiency.
Complies with automotive standard AEC-Q101 for enhanced reliability.
Discover a broad range of Transient Voltage Suppressors and other semiconductor components in the Electronics & Electricals category at EnvMart, catering to industrial, automotive, and commercial electronics applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is 1500 watts, providing robust surge protection for sensitive electronic components.
The clamping voltage for this transient voltage suppressor is 58.1 V, which helps limit voltage overshoot during transients.
This unit operates within a temperature range of -55°C to 150°C, ensuring reliable performance under various environmental conditions.
The maximum reverse stand-off voltage rating for this model is 36 V, providing effective protection against voltage transients.
This transient voltage suppressor has a maximum peak pulse current capability of 25.8 A, allowing it to handle significant transient events.
It uses a compact DO-214AB (SMC) surface mount package, which facilitates easy installation on PCBs.
This model features a 2-pin configuration, suitable for compact electronic designs.
It complies with the automotive standard AEC-Q101, ensuring enhanced reliability for automotive applications.
The maximum reverse leakage current for this unit is 1 microampere, contributing to its energy efficiency.
The minimum breakdown voltage of this transient voltage suppressor is 40 V, ensuring effective operation during voltage transients.
This device is suitable for applications such as industrial power supplies, voltage transient suppression in control and communication equipment, and automotive electronic systems.
The dimensions of this transient voltage suppressor are 2.42 mm in height, 7.11 mm in length, and 6.22 mm in width.
