Panasonic Surface Signal Relay, 5V DC Coil, 2A Switching Current, DPDT Contact Configuration TXD2SA-5V
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 8.2mm |
| Length | 15mm |
| Model | TXD2SA-5V |
| Width | 7.4mm |
| Mount Type | Surface |
| Contact Material | Gold Plated |
| Series | G6K |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | Surface Mount |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 699-6437Brand: PanasonicManufacturers Part No.: TXD2SA-5V |
| Coil Resistance | 89Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 220V ac |
| Coil Power | 200mW |
Key Features
- This relay supports a coil voltage of 5V DC ensuring efficient power consumption.
- It features a double-pole double-throw (DPDT) contact configuration for versatile switching operations.
- The switching current rating of 2A accommodates moderate electrical loads.
- The unit has a compact surface mount design ideal for PCB assembly with dimensions of 15 mm length, 7.4 mm width, and 8.2 mm height.
- It withstands a wide operating temperature range from -40°C to 85°C enabling use in demanding environments.
- The coil resistance is 89 Ohms with a coil power consumption of 200 mW for low energy operation.
- Gold plated contacts ensure durability and reliable electrical connectivity.
- The relay meets RoHS compliance standards and is manufactured in Japan ensuring quality and environmental safety.
Product Description
Panasonic TXD2SA-5V is a surface mount signal relay designed for reliable and efficient switching in various electrical and automation systems. Featuring a 5V DC coil, this relay provides a switching current capacity of 2A with double-pole double-throw (DPDT) contact configuration, suitable for controlling multiple circuits simultaneously.
Its compact dimensions (15 mm length, 7.4 mm width, and 8.2 mm height) and surface mount terminal type make it ideal for PCB integration in electronic equipment. The relay's coil resistance of 89 Ohms and coil power of 200 milliwatts allow for low power consumption and efficient operation.
Engineered to endure harsh conditions, the TXD2SA-5V operates effectively across a temperature range from -40°C to 85°C. The gold plated contact material ensures superior conductivity and resistance to corrosion, enhancing the relay's lifespan.
This relay is compliant with RoHS regulations and meets supplementary insulation class standards in EN60950, providing safety and environmental assurance. Typical industrial, laboratory, and electronic applications include fax machines, modems, medical instruments, automotive electronics, and security equipment where reliable signal switching is critical.
Supports 5V DC coil voltage for efficient operation. DPDT contact configuration for flexible circuit switching. 2A switching current suitable for various load requirements. Compact surface mount package for PCB integration.
Wide operating temperature range from -40°C to 85°C. Coil resistance of 89Ω and coil power consumption of 200mW. Gold plated contacts for reliable electrical performance. RoHS compliant and manufactured in Japan ensuring quality and safety.
Explore EnvMart’s wide range of high quality Signal Relays for diverse industrial, electronic, and automation applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 5V DC, which ensures efficient power consumption during operation.
The relay has a switching current rating of 2A, making it suitable for moderate electrical loads.
It features a double-pole double-throw (DPDT) contact configuration, allowing for versatile switching operations.
This model has compact dimensions of 15 mm in length, 7.4 mm in width, and 8.2 mm in height, making it ideal for PCB assembly.
The relay operates effectively within a wide temperature range from -40°C to 85°C, suitable for demanding environments.
The coil resistance of this relay is 89 Ohms, which contributes to its low power consumption.
The coil power consumption is 200 mW, allowing for low energy operation.
The contacts are made of gold plated material, ensuring reliable electrical connectivity and resistance to corrosion.
Yes, it meets RoHS compliance standards, ensuring environmental safety and quality.
Typical applications include fax machines, modems, medical instruments, automotive electronics, and security equipment where reliable signal switching is critical.
The TXD2SA-5V features a surface mount terminal type, making it suitable for integration into electronic equipment.
The relay can switch both DC and AC voltages up to 220V, making it versatile for various applications.
