Panasonic Surface Signal Relay 3V DC Coil 2A DPDT Surface Mount PCB Terminal TX2-3V-TH

Panasonic TX2-3V-TH Surface Signal Relay is a high-performance, surface mount relay designed for industrial automation and electrical control systems. This signal relay operates with a low 3V DC coil voltage and features a double pole double throw (DPDT) contact configuration capable of switching currents up to 2 amps and AC/DC voltages up to 220 volts, making it suitable for a wide range of control and automation applications.

With compact dimensions of 15mm length, 8.2mm height, and 7.4mm width, it is ideal for installation on printed circuit boards where space saving is critical. The relay incorporates gold-plated contacts to ensure high reliability and durable electrical performance. Its coil resistance of 64.3 ohms and low power coil consumption of 140mW provide energy-efficient operation.

The TX2-3V-TH relay has a sealed construction that offers excellent surge resistance, shock, and vibration tolerance along with the ability to withstand automatic washing processes, ensuring robustness in industrial environments. It is engineered to perform reliably within a wide temperature range from -40°C up to 85°C, accommodating various operating conditions.

Typical industrial use cases include air conditioning controls, signal switching in manufacturing automation, HVAC control systems, power management, and other high-capacity control functions requiring dependable switching performance.

Operates with low power 3V DC coil voltage for energy efficiency. DPDT contact configuration supports complex switching arrangements. Compact size and surface mount design enable easy integration in PCB applications. Gold plated contacts provide superior conductivity and corrosion resistance.

Wide operating temperature range from -40°C to 85°C for harsh environments. Sealed relay housing to protect against shock, vibration, and contamination. Supports switching currents up to 2A AC/DC at 220 volts rating. Resilient design allows applications in automation, HVAC, and industrial controls.

Coil resistance and power ratings optimize energy usage and reliability. Manufactured in Japan, assuring premium quality and adherence to safety standards.
