APEM Raised Rotary Coded DIP Switch Through Hole NDS-02-V

APEM NDS-02-V Raised Rotary Coded DIP Switch Through Hole is a precision-engineered SPST switch featuring a raised actuator for enhanced operability. It mounts through-hole, providing robust mechanical and electrical connections ideal for demanding industrial and commercial electronic applications.

This rotary coded DIP switch series is widely applied in telecom systems, computer hardware, test equipment, security devices, and instrumentation, ensuring accurate position selection and tactile feedback.

Key operational features include a maximum actuation force of 10N, 2mm stroke length, and rated switching capabilities of 25mA at 24Vdc, supporting up to 100mA at 50Vdc for non-switching conditions. These specifications ensure reliable performance under typical electrical loads.

The switch’s through-hole mounting type offers easy integration on printed circuit boards with strong mechanical stability. The raised actuator design improves user accessibility and switch actuation.

This product is manufactured in China, meeting industry quality protocols. It complements industrial automation systems, telecommunications infrastructure, laboratory instrumentation, and security electronics.

This rotary coded DIP switch features a raised actuator type for ease of use. The through-hole mount type ensures secure and stable PCB attachment. It operates with a maximum operation force of 10N and 2mm stroke for reliable switching.

The switch supports 25mA at 24Vdc for switching rating and 100mA at 50Vdc for non-switching rating. Designed for SPST configurations in the NDS series with an array of selectable positions. Manufactured with quality standards and has a country of origin of China.
