Bourns 1.5 A Resettable Fuse 24V, 1812 SMT Package, Gold Plated Nickel Terminal MF-MSMF150/24X-2
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 24V |
| Brand | Bourns |
| Height | 1.6mm |
| Length | 4.83mm |
| Model | MF-MSMF150/24X-2 |
| Width | 3.41mm |
| Current Rating | 20A |
| Series | MF-MSMF |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -40°C |
| Package Size | 1812 |
| Trip Current | 3A |
| Power Dissipation | 1.2W |
| Terminal Material | Gold Plated Nickel |
| Standards/Approvals | RoHS, UL |
| Time to Trip | 1.5s |
| Hold Current | 1.5A |
| Minimum Resistance | 0.02Ω |
| Maximum Resistance | 100mΩ |
Key Features
- Rated for a hold current of 1.5 A ensuring protection against overcurrent conditions.
- Time to trip is 1.5 seconds for quick response to fault conditions.
- Compact dimensions measuring 4.83 mm length, 3.41 mm width, and 1.6 mm height.
- Operates within a temperature range from -40°C to 60°C for versatile application environments.
- Power dissipation rated at 1.2 W supporting efficient thermal management.
- Compliant with RoHS and UL standards for safety and environmental requirements.
- Compatible with Pb and Pb-free solder for flexible manufacturing processes.
- Designed with AEC-Q200 automotive passives stress test qualification assuring device reliability.
Product Description
Bourns MF-MSMF150/24X-2 is a 1.5 A resettable fuse designed for 24V circuit protection with a compact standard 1812 surface-mount package footprint. It features gold plated nickel terminals that ensure reliable electrical connections and long-term durability.
This fuse provides a hold current of 1.5 A and a trip current of 3 A with a rapid time to trip of 1.5 seconds. Its power dissipation of 1.2 W allows it to efficiently manage heat in electronic circuits. Operating temperature ranges from -40°C to 60°C make it suitable for demanding industrial and automotive applications.
The device meets RoHS and UL standards and is compliant with AEC-Q200 Rev-D, demonstrating its suitability for automotive passive component stress tests. The surface mount packaging conforms to the standard 4532 mm footprint, compatible with both Pb and Pb-free soldering processes.
Resettable fuses such as this are used widely in industrial automation, electronics manufacturing, and automotive systems for efficient circuit protection and fault tolerance. Rated for a hold current of 1.5 A ensuring protection against overcurrent conditions.
Time to trip is 1.5 seconds for quick response to fault conditions. Compact dimensions measuring 4.83 mm length, 3.41 mm width, and 1.6 mm height. Operates within a temperature range from -40°C to 60°C for versatile application environments.
Power dissipation rated at 1.2 W supporting efficient thermal management. Compliant with RoHS and UL standards for safety and environmental requirements. Compatible with Pb and Pb-free solder for flexible manufacturing processes.
Designed with AEC-Q200 automotive passives stress test qualification assuring device reliability. Explore similar Resettable Fuse options and other circuit protection products from leading manufacturers on EnvMart for your industrial, automotive, and electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The hold current rating of this resettable fuse is 1.5 A, providing protection against overcurrent conditions.
The trip current for this model is 3 A, ensuring a rapid response to fault conditions.
This resettable fuse has a time to trip of 1.5 seconds, allowing for quick response during overcurrent situations.
The dimensions of this fuse are 4.83 mm in length, 3.41 mm in width, and 1.6 mm in height.
It operates within a temperature range of -40°C to 60°C, making it suitable for various application environments.
The power dissipation rating is 1.2 W, which supports efficient thermal management in electronic circuits.
This resettable fuse is compliant with RoHS and UL standards, ensuring safety and environmental requirements are met.
It features gold plated nickel terminals, which ensure reliable electrical connections.
Yes, it is compatible with both Pb and Pb-free solder, allowing for flexible manufacturing processes.
This resettable fuse is widely used in industrial automation, electronics manufacturing, and automotive systems for circuit protection.
The minimum resistance is 0.02Ω and the maximum resistance is 100mΩ, ensuring effective current flow.
The package size of this resettable fuse is 1812, conforming to standard surface-mount dimensions.
