Littelfuse 1.1 A Resettable Fuse 6V DC 60 V DC Surface Mount 2016L100/33DR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 6, 60V dc |
| Brand | Littelfuse |
| Height | 1.25mm |
| Length | 5.44mm |
| Model | 2016L100/33DR |
| Width | 4.43mm |
| Series | 2016L |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Package Size | 0.20 x 0.16 in |
| Trip Current | 2.2A |
| Power Dissipation | 1.4W |
| Terminal Material | Solder Plated Copper |
| Standards/Approvals | RoHS, MIL-STD-883, ANSI/J-STD-002, MIL-STD-202, EIA Specification RS186-9E |
| Time to Trip | 0.5s |
| Hold Current | 1.1A |
| Minimum Resistance | 0.1Ω |
| Maximum Resistance | 400mΩ |
Key Features
- Offers a trip current of 2.2 A ensuring safe circuit protection.
- Operates at voltages of 6 V DC and 60 V DC.
- Rapid trip time of 0.5 seconds to protect sensitive components.
- Compact surface mount package size of 0.20 x 0.16 inches for efficient PCB integration.
- Constructed with solder plated copper terminals for excellent conductivity.
- Power dissipation capability of 1.4 W suitable for low voltage circuits.
- Wide operating temperature range from -40°C to 85°C for durability in various environments.
- Complies with RoHS, MIL-STD-883, ANSI/J-STD-002, MIL-STD-202 and EIA RS186-9E standards.
Product Description
The Littelfuse 2016L100/33DR is a high-quality resettable fuse designed for precise overcurrent protection in low voltage electrical circuits. Featuring a hold current of 1.1 A and a trip current of 2.2 A, this fuse provides timely protection with a rapid trip time of 0.5 seconds. It is rated for 6 V DC and 60 V DC applications, making it versatile for a range of electronics applications.
Its compact surface mount package of 0.20 x 0.16 inches and dimensions of 5.44 mm length, 4.43 mm width, and 1.25 mm height allow for space-efficient placement on circuit boards. The solder plated copper terminals ensure reliable electrical connections and conductivity while maintaining durability.
The model supports power dissipation up to 1.4 W and operates efficiently across a broad temperature range, from -40°C to 85°C. These characteristics make it highly reliable in demanding industrial, telecom, automotive, and medical environments.
It complies with respected standards including RoHS, MIL-STD-883, ANSI/J-STD-002, MIL-STD-202, and EIA Specification RS186-9E, guaranteeing compliance with industry regulations for safety and performance.
This resettable fuse is ideal for protecting sensitive components such as silicon ICs, alarm systems, audio/visual equipment, computer boards, portable devices, and power supplies. Its surface mount technology offers space-saving and fast installation features, promoting greater manufacturing efficiency.
Trip current of 2.2 A for reliable circuit protection. Voltage ratings of 6 V DC and 60 V DC. Quick response time of 0.5 seconds. Compact surface mount package optimized for PCB use. Durable solder plated copper terminals for excellent conductivity.
Power dissipation up to 1.4 W supports low voltage applications. Wide temperature operation from -40°C to 85°C. Compliant with multiple industrial and environmental standards. Suitable for telecom, automotive, industrial, and medical electronics protection.
Explore more Littelfuse Resettable Fuses and electronic protection devices at EnvMart to enhance your circuit safety and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The trip current of this model is 2.2 A, ensuring reliable circuit protection.
It operates at voltages of 6 V DC and 60 V DC, making it suitable for a variety of low voltage applications.
The fuse features a rapid trip time of 0.5 seconds, providing timely protection for sensitive components.
This model has dimensions of 5.44 mm in length, 4.43 mm in width, and 1.25 mm in height.
It supports power dissipation up to 1.4 W, making it suitable for low voltage circuits.
The operating temperature range is from -40°C to 85°C, allowing for use in various environments.
It is constructed with solder plated copper terminals, ensuring excellent conductivity.
This model complies with RoHS, MIL-STD-883, ANSI/J-STD-002, MIL-STD-202, and EIA Specification RS186-9E standards.
The hold current rating for this resettable fuse is 1.1 A, which is the maximum current it can continuously carry without tripping.
It comes in a compact surface mount package type, optimized for efficient PCB integration.
This resettable fuse is suitable for protecting sensitive components in applications such as telecom, automotive, industrial, and medical electronics.
The minimum resistance is 0.1Ω and the maximum resistance is 400mΩ, ensuring effective overcurrent protection.
