Bourns 1.6 A Radial Leaded Resettable Fuse 72V MF-RX160/72-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 72V |
| Brand | Bourns |
| Height | 19.94mm |
| Length | 13.94mm |
| Model | MF-RX160/72-0 |
| Width | 3.1mm |
| Current Rating | 40A |
| Series | MF-RX/72 |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Trip Current | 3.2A |
| Power Dissipation | 1.9W |
| Standards/Approvals | RoHS, UL |
| Lead Diameter | 0.81mm |
| Time to Trip | 11.4s |
| Hold Current | 1.6A |
| Minimum Resistance | 0.09Ω |
| Maximum Resistance | 220mΩ |
| Lead Orientation | Radial |
Key Features
- The fuse automatically resets itself thousands of times, offering maintenance-free operation.
- Constructed with cured, flame retardant epoxy polymer insulating material complying with UL 94V-0.
- Features rapid switching from low resistance state to high resistance on electrical overload or short circuit.
- Small size without requiring a fuse holder, with radial lead orientation for easy PCB mounting.
- Main applications include security systems, power supplies, transformers, automotive, medical equipment, and instrumentation.
- Designed to protect electrical and electronic circuits against excessive currents effectively.
- Complies with RoHS and UL standards for safety and environmental compliance.
- The fuse offers a hold current of 1.6 A and a trip current of 3.2 A for precise protection.
Product Description
Bourns MF-RX160/72-0 is a radial leaded resettable fuse with a current rating of 1.6 A and a maximum operating voltage of 72V. It provides automatic circuit protection by switching rapidly from a low resistance state to a very high resistance state in the event of overcurrent or short circuit conditions.
The fuse is constructed from cured, flame retardant epoxy polymer insulating material that meets the UL 94V-0 flammability standard, ensuring durability and safety in demanding environments. It eliminates the need for fuse holders due to its compact size and PCB wire-ended design.
This resettable fuse can automatically reset thousands of times after fault clearance, making it ideal for maintenance-free applications. It is UL, CSA, and TUV approved, assuring compliance with international safety standards.
Typical industrial and commercial use cases include security systems, power supplies, transformers, automotive and medical equipment, instrumentation and control devices, computers, audio-visual systems, and telecommunications equipment. The fuse provides reliable protection against excessive currents, enhancing the durability of connected components.
Automatically resets thousands of times for continuous protection. Cured epoxy polymer encapsulation meets UL 94V-0 flame retardancy. Low resistance to high resistance switch on fault conditions. Maintenance-free, small size design with no fuseholder required.
Radial leaded device suitable for PCB mounting. Compliant with RoHS and UL standards. Trip current of 3.2 A and hold current of 1.6 A for precision protection. Power dissipation rated at 1.9 W to handle thermal loads safely.
Protect your electronic circuits with this reliable Resettable Fuse from Bourns, featuring robust performance and safety certifications. Explore more quality circuit protection devices in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns MF-RX160/72-0 fuse has a current rating of 1.6 A.
This resettable fuse operates at a maximum voltage of 72V.
The dimensions of this fuse are 19.94 mm in height, 13.94 mm in length, and 3.1 mm in width.
The trip current for the MF-RX160/72-0 is 3.2 A.
The hold current rating of this resettable fuse is 1.6 A.
This fuse has a power dissipation rating of 1.9 W.
The fuse is constructed with cured, flame retardant epoxy polymer insulating material that complies with UL 94V-0.
The operating temperature range for this fuse is from -40°C to 85°C.
The time to trip for the MF-RX160/72-0 is 11.4 seconds.
This resettable fuse is suitable for applications including security systems, power supplies, transformers, automotive, medical equipment, and instrumentation.
Yes, the fuse complies with RoHS and UL standards for safety and environmental compliance.
The lead orientation for the MF-RX160/72-0 is radial, which is suitable for PCB mounting.
