Omron Hinge Lever Micro Switch, PCB Terminal, 2A, 250V AC, 30V DC, SPDT, IP67, D2SW-P2L1B
Specifications
| Country of Origin | China |
|---|---|
| Brand | Omron |
| Operating Temperature Range | -40 to +80°C |
| Model | D2SW-P2L1B |
| IP Rating | IP67 |
| Width | 6.4mm |
| Series | D2SW-P |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPDT |
| Actuator Type | Hinge Lever |
| Contact Rating | 3A@30Vdc/125Vac, 2A@250Vac |
| Minimum Operating Temperature | -20°C |
| Terminal type | PCB Terminal |
| Standards/Approvals | RoHS |
| Contact DC Voltage | 30V dc |
| Switch Contact Current | 2A |
| Operating Force | 0.6N |
| Mechanical Life | 1000000Operations |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Sealed Subminiature |
Key Features
- The switch features a hinge lever actuator for precise mechanical operation.
- Equipped with a PCB terminal for secure electrical connection.
- Offers a contact current rating of 2A and voltage tolerances of 250V AC and 30V DC.
- Constructed with IP67 protection for resistance against dust and water ingress.
- Has a mechanical life of one million operations for durable performance.
- Operates in a temperature range from -40°C to +80°C ensuring versatility.
- Low operating force of 0.6N facilitates sensitive actuation.
- Complies with RoHS standards for environmental safety.
Product Description
Omron D2SW-P2L1B Hinge Lever Micro Switch with PCB terminal provides reliable switching operation rated at 2A, 250V AC, and 30V DC. This sealed subminiature switch incorporates a hinge lever actuator designed for mechanical precision and durability.
The micro switch is constructed with monoblock sealed miniature housing that offers high sealing capability ideal for environments with dust or water exposure, supported by an IP67 rating. Its robust design ensures a mechanical life of 1,000,000 operations, making it suitable for long-term industrial use.
Operating temperature ranges from -40°C to +80°C, allowing the switch to function effectively in harsh environments. The low operating force of 0.6N ensures sensitive and consistent actuation in automation and electrical control applications.
Compliant with RoHS directives, this micro switch is environmentally friendly and safe for use in sensitive electronic systems. The compact 6.4mm width design allows for space-efficient installations on PCBs.
Package contains one Omron D2SW-P2L1B sealed hinge lever micro switch with PCB terminal. The switch’s SPDT contact configuration enables versatile switching functions. Supports contact ratings of 3A at 30V DC/125V AC and 2A at 250V AC for varied electrical loads.
Ideal for industrial automation, electrical equipment, and control panels. Durable sealed construction suitable for dusty or wet environments. Ensures reliable switching performance throughout its operational life. Explore further Omron Micro Switch products and options to meet diverse electrical and automation needs here at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contact rating is 2A at 250V AC and 3A at 30V DC.
It has an IP67 rating, providing protection against dust and water ingress.
The operating temperature range is from -40°C to +80°C.
This model features a hinge lever actuator for precise mechanical operation.
The mechanical life is rated for 1,000,000 operations.
The width of the switch is 6.4mm, allowing for space-efficient PCB installations.
It is equipped with a PCB terminal for secure electrical connections.
The operating force is 0.6N, facilitating sensitive actuation.
Yes, it complies with RoHS standards for environmental safety.
It is suitable for industrial automation, electrical equipment, and control panels.
The contact configuration is SPDT (Single Pole Double Throw).
The maximum operating temperature is 70°C.
