Microchip 12-bit 2-Channel Digital to Analogue Converter Resistor String Architecture SPI 8-Pin MSOP MCP4822-E/MS
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Microchip |
| Height | 1.7mm |
| Length | 4.9mm |
| Model | MCP4822-E/MS |
| Width | 3.9mm |
| Mount Type | Surface |
| Settling Time | 4.5μs |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Interface Type | Microwire, SPI |
| Architecture | Resistor String |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 5V |
Key Features
- Provides 12-bit resolution for precise analogue output control.
- Features two independent output channels for versatile applications.
- Utilizes Microwire and SPI interface communication protocols.
- Compact 8-pin MSOP surface mount package enables space-efficient PCB design.
- Operates within -40°C to 125°C temperature range ensuring robust industrial performance.
- Minimum supply voltage of 5V with a maximum of 5.5V for stable power supply.
- Fast settling time of 4.5 microseconds for rapid output changes.
- Internal voltage reference simplifies design integration.
Product Description
Microchip MCP4822-E/MS is a 12-bit, 2-channel digital to analogue converter designed with resistor string architecture and housed in an 8-pin MSOP surface mount package. Operating with a supply voltage range of 5V to 5.5V and supporting Microwire and SPI interface protocols, this DAC provides reliable analogue voltage output for industrial and electronic applications.
The device features two independent output channels allowing simultaneous dual signal generation. It operates efficiently across a wide temperature range from -40°C to 125°C, making it suitable for demanding environments. Its fast settling time of 4.5 microseconds enhances performance in systems requiring rapid response.
This DAC includes an internal voltage reference, simplifying circuit design and minimizing external components. Compact physical dimensions of 4.9mm length, 3.9mm width, and 1.7mm height allow it to fit in space-constrained PCB layouts.
Typical applications include industrial control systems, signal generation, instrumentation, and embedded electronics where precise analogue conversion is critical. Provides 12-bit resolution for precise analogue output control.
Features two independent output channels for versatile applications. Utilizes Microwire and SPI interface communication protocols. Compact 8-pin MSOP surface mount package enables space-efficient PCB design. Operates within -40°C to 125°C temperature range ensuring robust industrial performance.
Minimum supply voltage of 5V with a maximum of 5.5V for stable power supply. Fast settling time of 4.5 microseconds for rapid output changes. Internal voltage reference simplifies design integration. Designed for analogue voltage output suitable for control and measurement systems.
Package dimensions optimized as 4.9mm length, 3.9mm width, and 1.7mm height.
This Microchip DAC is an ideal choice for electronic component inventories focused on dependable and compact digital-to-analogue conversion solutions. Explore similar products in the Digital to Analogue Converter category within the Semiconductor segment on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a resolution of 12 bits for precise analogue output control.
It features two independent output channels, allowing for versatile applications and simultaneous dual signal generation.
This unit utilizes Microwire and SPI interface communication protocols for reliable data transfer.
The device operates with a minimum supply voltage of 5V and a maximum of 5.5V for stable power supply.
It has a fast settling time of 4.5 microseconds, enabling rapid output changes.
The package dimensions are 4.9mm in length, 3.9mm in width, and 1.7mm in height, making it suitable for space-constrained PCB layouts.
It operates efficiently within a temperature range of -40°C to 125°C, suitable for demanding industrial environments.
This digital to analogue converter provides an analogue voltage output, making it suitable for control and measurement systems.
It is designed with a resistor string architecture, which is common in digital to analogue converters.
The MCP4822-E/MS has a pin count of 8, allowing for compact integration in electronic designs.
The country of origin for this model is India.
Typical applications include industrial control systems, signal generation, instrumentation, and embedded electronics requiring precise analogue conversion.
