MEAN WELL IP67 1 Output LED Driver, 36V, 18W, 0.5A Constant Voltage Enclosed AC-DC Power Supply
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | MEAN WELL |
| Model | IP67 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | LPH-18 |
| Configuration | Enclosed |
| Sub Type | LED Driver |
| Operating Modes | Constant Voltage |
| Number of outputs | 1 |
| Terminal type | Wire |
| Maximum Output Power | 18W |
| Input Voltage | 180, 264, 254, 370V ac |
| Output Voltage | 36V |
| Power Dissipation | 18W |
| Standards/Approvals | UL, EN, CSA, CE |
| Primary Type | AC-DC |
| Driver Current | 0.5A |
| MEAN WELL IP67 1 Output LED Driver, 12V, 18 W, 1.5A LED DriverBrand | MEAN WELL |
| MEAN WELL, 16.2W Output, 450mA Output, Constant VoltageBrand | RS PRO |
Key Features
- The LED driver features IP67 waterproof rating suitable for indoor and outdoor environments.
- It operates with an input voltage range of 180 to 370V AC and provides fully regulated output.
- Equipped with built-in protections for short circuit, overload, over-voltage, and over-temperature conditions.
- Designed for LED lighting and moving sign applications requiring reliable constant voltage drive.
- Complies with UL, EN, CSA, CE standards and offers a panel mount type configuration.
- Includes un-terminated 2-core 18AWG input and output wires each 300mm in length for easy installation.
- Meets EMC compliance to EN 55022 Class B and harmonic current compliance to EN 61000-3-2/-3.
- UL1310 Class 2 power unit pass for safety and has a mean time between failures (MTBF) per MIL-HDBK-217F standards.
Product Description
MEAN WELL LPH-18-36 is an IP67 rated, 1 output LED driver designed for industrial applications demanding robust, reliable AC to DC constant voltage power supply. With a maximum output power of 18W and a 36V output voltage, this enclosed driver supports LED lighting installations including indoor and outdoor signage and moving light displays.
Equipped with 0.5A driver current, it operates under input AC voltages ranging from 180V to 370V. The driver includes multiple protections such as short circuit, overload, over-voltage, and over-temperature safeguards ensuring safe and long life operation.
Constructed to meet international standards including UL, EN, CSA, and CE certifications, and featuring an IP67 waterproof rating, this unit is suitable for harsh environments. The panel mount form factor and built-in wiring terminals support versatile deployment in electrical and electronic systems.
MEAN WELL LPH-18-36 undergoes 100% full load burn-in test for quality assurance and carries EMC compliance to EN 55022 Class B along with harmonic current standards EN 61000-3-2,-3. It features a 300mm un-terminated 2-core 18AWG input and output leads, facilitating straightforward installation.
This product is ideal for industrial, commercial, and outdoor LED lighting systems, water-resistant lighting fixtures, and moving signs requiring constant voltage power with high efficiency and dependable protection mechanisms.
The LED driver features IP67 waterproof rating suitable for indoor and outdoor environments. It operates with an input voltage range of 180 to 370V AC and provides fully regulated output. Equipped with built-in protections for short circuit, overload, over-voltage, and over-temperature conditions.
Designed for LED lighting and moving sign applications requiring reliable constant voltage drive. Complies with UL, EN, CSA, CE standards and offers a panel mount type configuration. Includes un-terminated 2-core 18AWG input and output wires each 300mm in length for easy installation.
Meets EMC compliance to EN 55022 Class B and harmonic current compliance to EN 61000-3-2/-3. UL1310 Class 2 power unit pass for safety and has a mean time between failures (MTBF) per MIL-HDBK-217F standards. Explore our range of LED drivers and lighting components on EnvMart for reliable industrial power solutions.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this LED driver is 18W.
It operates with an input voltage range of 180 to 370V AC.
The output voltage of this driver is 36V.
This model provides 1 output.
It includes protections for short circuit, overload, over-voltage, and over-temperature conditions.
The driver current for this model is 0.5A.
This driver supports a panel mount type configuration.
The IP rating of this model is IP67, making it suitable for both indoor and outdoor environments.
The driver includes un-terminated 2-core 18AWG input and output wires, each 300mm in length.
It complies with UL, EN, CSA, and CE standards.
Yes, it is designed for outdoor applications due to its IP67 waterproof rating.
The country of origin for this model is Taiwan.
