Sunhayato 2 Matrix Board 0.9 mm Holes, 2.54 mm Pitch, 190 mm Length, 95 mm Width ICB-502H-PBF
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Sunhayato |
| Length | 190mm |
| Model | ICB-502H-PBF |
| Width | 95mm |
| Hole Diameter | 0.9mm |
| Board Material | Glass Composite |
| Standards/Approvals | BS EN 61340, ANSI/ESD S20 |
| Number of Sides | 2 |
| Board Thickness | 1.6mm |
| Hole Pitch | 2.54mm |
Key Features
- The board has a thickness of 1.6 mm ensuring durability during prototyping.
- Manufactured from glass composite material offering excellent rigidity and stability.
- Compliant with standards BS EN 61340 and ANSI/ESD S20 for ESD control reliability.
- Dual-sided design provides versatile mounting options for electronic components.
- Suitable for prototyping and assembly in electronics and electrical engineering projects.
- Originated from Japan, reflecting high manufacturing quality and standards.
- 0.9 mm hole diameter facilitates easy installation of standard electrical components.
- Ideal for cleanroom and ESD control environments to prevent static discharge damage.
Product Description
Sunhayato ICB-502H-PBF Matrix Board is a high-quality prototyping board designed for professional electronics and electrical component assembly. With precise 0.9 mm diameter holes arranged at a 2.54 mm pitch, this board offers reliable and accurate placement for components with standardized spacing.
Measuring 190 mm in length and 95 mm in width, the board thickness is 1.6 mm, crafted from robust glass composite material that ensures durability and excellent electrical isolation properties, making it suitable for demanding industrial applications.
This matrix board features a dual-sided configuration which provides enhanced versatility when prototyping complex circuits or electronic systems. It is compliant with stringent standards such as BS EN 61340 and ANSI/ESD S20, making it highly effective in environments where electrostatic discharge control is critical.
Produced in Japan, this board reflects superior quality control and manufacturing excellence. It is particularly suitable for use in laboratories, research and development facilities, educational institutions, manufacturing, and quality control labs.
The board thickness of 1.6 mm offers a balance between strength and component mounting flexibility. Glass composite board material provides rigidity and excellent dielectric properties. 2.54 mm hole pitch adheres to industry-standard spacing, compatible with a wide variety of electronic components.
0.9 mm hole diameter allows for secure insertion and soldering of components. Dual-sided design increases mounting options for advanced prototyping needs. Compliance with BS EN 61340 and ANSI/ESD S20 ensures safety against electrostatic discharge damage.
Medium-sized universal lead-free board suitable for diverse prototyping and development applications.
Incorporate the Sunhayato ICB-502H-PBF Matrix Board into your electronic prototyping process for reliable performance and precise circuit design. Ideal for use in ESD control, cleanrooms, and various industrial, laboratory, and manufacturing environments.
Explore a wide range of high-quality prototyping solutions and electronics components at EnvMart for your professional projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This matrix board measures 190 mm in length and 95 mm in width.
It features a hole diameter of 0.9 mm and a hole pitch of 2.54 mm.
The board is manufactured from glass composite material, providing excellent rigidity and stability.
The board has a thickness of 1.6 mm, balancing strength and component mounting flexibility.
Yes, it complies with BS EN 61340 and ANSI/ESD S20 standards for ESD control reliability.
It is suitable for prototyping and assembly in electronics and electrical engineering projects, particularly in ESD control environments.
Yes, it features a dual-sided design, allowing for versatile mounting options for electronic components.
It is particularly suitable for use in laboratories, research and development facilities, and manufacturing environments.
This matrix board is manufactured in Japan, reflecting high manufacturing quality and standards.
The 0.9 mm hole diameter facilitates easy installation and secure soldering of standard electrical components.
The 1.6 mm thickness provides a balance between durability and flexibility for component mounting during prototyping.
Yes, it is ideal for cleanroom and ESD control environments to prevent static discharge damage.
