Murata 24 MHz Crystal Unit ±10 ppm Surface Mount 4-Pin 0.65 mm Height 1.6 mm Length 2 mm Width XRCGB24M000F1SBDR0

Free Delivery in India | Lowest Global Shipping Charges

Murata 24 MHz Crystal Unit ±10 ppm Surface Mount 4-Pin 0.65 mm Height 1.6 mm Length 2 mm Width XRCGB24M000F1SBDR0

Name: Murata 24 MHz Crystal Unit ±10 ppm Surface Mount 4-Pin 0.65 mm Height 1.6 mm Length 2 mm Width XRCGB24M000F1SBDR0
Brand: Murata
SKU: 340055
Price: 0.3 USD
Availability: InStock



Category Crystal Unit Brand Murata Condition New

Specifications

Country of Origin	Japan
Brand	Murata
Height	0.65mm
Length	1.6mm
Model	XRCGB24M000F1SBDR0
Packaging	Tape
Width	2mm
Mount Type	Surface
Series	XRCGB
Maximum Operating Temperature	105°C
Package Type	Surface Mount
Minimum Operating Temperature	-40°C
Pin Count	4
Standard Frequency	24MHz
Load Capacitance	12pF
Series Resistance	70Ω

Key Features

Standard frequency of 24 MHz ensures stable oscillation.
Surface mount package with 4 pins minimizes PCB space requirements.
Compact size of 1.6 mm length, 2 mm width, and 0.65 mm height for small form-factor devices.
Load capacitance of 12 pF for accurate frequency control.
Wide operating temperature range from -40°C to 105°C for robust performance.
Series resistance of 70 Ω ensures efficient signal stability.
Supplied on tape packaging facilitating automated placement.
Compliant with RoHS directive, lead-free and environmentally friendly.

Product Description

Murata XRCGB24M000F1SBDR0 24 MHz Crystal Unit is a high-precision surface mount electronic component with a frequency tolerance of ±10 ppm. Featuring a compact 4-pin design with dimensions of 1.6 mm length, 2 mm width, and 0.65 mm height, this crystal unit is optimized for use in modern electronic assemblies requiring stable timing references.

This crystal unit delivers a load capacitance of 12 pF and a series resistance of 70 Ω, providing excellent frequency stability and signal integrity. It operates reliably within a temperature range of -40°C to 105°C, making it suitable for diverse industrial, communication, and consumer electronics applications such as PCs, visual equipment, Wi-Fi, and Bluetooth technology.

Its tape packaging supports efficient mass production and automated pick-and-place assembly. Complying fully with RoHS environmental standards, the unit promotes sustainable electronics manufacturing.

Standard frequency of 24 MHz ensures stable oscillation. Surface mount package with 4 pins minimizes PCB space requirements. Compact size of 1.6 mm length, 2 mm width, and 0.65 mm height for small form-factor devices. Load capacitance of 12 pF for accurate frequency control.

Wide operating temperature range from -40°C to 105°C for robust performance. Series resistance of 70 Ω ensures efficient signal stability. Supplied on tape packaging facilitating automated placement. Compliant with RoHS directive, lead-free and environmentally friendly.

Ideal for use in communication clocks such as Wi-Fi and Bluetooth devices. Manufactured in Japan, assuring high quality and reliability.

This crystal unit is an essential component for industrial, communication, laboratory, and consumer electronic devices requiring precise frequency control. Its compactness and reliability support advanced electronics manufacturing trends. Browse the Electronics Components section at EnvMart to explore Murata Crystal Units and related products for your design needs.
