Microchip 8 bit PIC16F Microcontroller 32 MHz 7kB FLASH 8-Pin SOIC PIC16F15214-I/SN

Microchip PIC16F15214-I/SN is an 8 bit microcontroller from the PIC16 series designed for cost-sensitive sensor and real-time control applications. It features a PIC16F device core and operates at a maximum clock frequency of 32 MHz, providing efficient processing capabilities in embedded systems.

This microcontroller comes in a compact 8-pin SOIC surface-mount package with dimensions of 4.9 mm length, 6 mm width, and 1.75 mm height, making it suitable for space-constrained designs.

It includes 7kB of FLASH program memory and 512 bit of RAM, supporting a range of applications requiring moderate code size and data capacity. The device supports 5 programmable input/output pins and 5 ADCs with 10-bit resolution for precise analog signal processing.

Operating voltage ranges from 1.8V to 5.5V, with a maximum power dissipation of 800mW, ensuring energy efficiency in various industrial and commercial systems. The microcontroller functions reliably over a wide temperature range from -40°C to 85°C, suitable for harsh environments.

The instruction set architecture is based on RISC principles, allowing for optimized instruction execution and simplified programming. This device complies with RoHS standards, ensuring environmental safety.

Operates with 8-bit PIC16F core architecture. 7kB FLASH memory and 512bit RAM for program and data storage. Maximum clock frequency of 32 MHz for high-speed operation. 8-pin SOIC package type designed for surface mounting.

Voltage supply range from 1.8 V to 5.5 V. Maximum power dissipation up to 800 mW. 5 programmable I/Os available for versatile interfacing. Operating temperature range from -40°C to 85°C for industrial applications. 5 analog-to-digital converters with 10-bit resolution.

RoHS compliant component for environmental standards.

This microcontroller is ideal for embedded control solutions in industrial automation, consumer electronics, and instrumentation fields. Its compact form factor and enhanced peripherals make it suitable for compact and energy-efficient systems requiring fast computation and reliable real-time control. Explore the Microchip range in the Microcontrollers category on EnvMart for high-performance Microcontroller solutions.
