Microchip 16 bit PIC Microcontroller 32 MHz 16kB FLASH 28-Pin QFN PIC24F
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Microchip |
| Height | 950μm |
| Length | 6mm |
| Model | PIC24F |
| Width | 6mm |
| Mount Type | Surface |
| Series | PIC24F |
| Maximum Operating Temperature | 85°C |
| Package Type | QFN |
| Minimum Operating Temperature | -40°C |
| Ram size | 2kB |
| Interface Type | MSSP |
| Standards/Approvals | RoHS |
| Pin Count | 28 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 1.8V |
| Device Core | PIC |
| Program Memory Size | 16kB |
| Maximum Clock Frequency | 32MHz |
| Analogue Comparators | 3 |
| Maximum Expanded Memory Size | 64MB |
| Number of Timers | 2 |
| Instruction Set Architecture | Modified Harvard |
| ADCs | 13 x 12 Bit |
| Program Memory Type | FLASH |
| System Supervisors | Low Power BOR, WDT, INT0 and RTCC |
Key Features
- This microcontroller features a 16-bit PIC core with modified Harvard architecture.
- It supports up to 32 MHz maximum clock frequency for efficient processing.
- The device contains 16kB of FLASH program memory and 2kB RAM for data storage.
- Equipped with 13 ADC channels of 12-bit resolution and 3 analogue comparators for high-precision analog input.
- Operates between 1.8V and 5.5V supply voltage with a temperature range from -40°C to 85°C.
- Includes 2 timers and system supervisors such as low power BOR, watchdog timer, INT0 and RTCC for reliable operation.
- Compact dimensions of 6mm x 6mm, 950μm height in a surface mount QFN package.
- Suitable for low power applications, providing eXtreme Low Power consumption modes.
Product Description
Microchip PIC24F16KA302-I/ML is a 16-bit PIC Microcontroller featuring a 32 MHz maximum clock frequency and 16kB of FLASH memory. Designed for embedded electronic applications, this microcontroller utilizes a modified Harvard architecture, delivering up to 16 MIPS performance with single cycle instruction execution.
The device integrates up to 13 channels of 12-bit ADCs and 3 analogue comparators, enabling precise analog signal processing. It supports a broad operating voltage range from 1.8V to 5.5V and temperature tolerance from -40°C to 85°C, making it ideal for harsh industrial and automotive environments.
Equipped with multiple system supervisors including low power Brown Out Reset (BOR), Watchdog Timer (WDT), INT0 interrupt, and Real Time Clock and Calendar (RTCC), the microcontroller ensures stable and safe operation. Its low power modes, such as Sleep, Doze, Idle, and Low-Voltage Sleep, optimize power consumption for battery-operated or energy-sensitive applications.
The form factor is a compact 28-pin Quad Flat No-lead (QFN) surface mount package with dimensions 6mm length, 6mm width, and a height of 950 micrometers. This microcontroller is well suited for industrial control, consumer electronics, medical devices, and automotive embedded systems where small size and advanced analog integration are critical.
This product supports both 3V and 5V applications. Includes flexible capture/compare/PWM modules and configurable logic cells for custom control functions. Internal oscillator ranging from 31 kHz up to 8 MHz with 4x PLL for clock speed scaling.
Fail-Safe Clock Monitor provides safe shutdown in case of clock failure. Manufactured to RoHS standards and originates from Thailand, this microcontroller maintains quality compliance for global electronics manufacturing.
Explore high-quality Microcontrollers and embedded solutions in the Electronics & Electricals category on EnvMart for industrial, laboratory, and commercial design projects.
