KEMET R41-T Film Capacitor Y2/X1 IEC 60384-14, ±10% Tolerance, 22 nF, 300V AC, 1.5 kV DC, Through Hole R413I222050T1K
Specifications
| Country of Origin | China |
|---|---|
| Brand | KEMET |
| Height | 12mm |
| Length | 18mm |
| Model | R413I222050T1K |
| Packaging | Bag |
| Width | 6mm |
| Mount Type | Through Hole |
| Series | R41-T |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -40°C |
| Dissipation Factor | 0.3% |
| Lead Length | 25mm |
| Pin Count | 2 |
| Rated AC Voltage | 300V ac |
| Rated DC Voltage | 1.5kV dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
| Suppression Class | Y2/X1 (IEC 60384-14) |
Key Features
- Metallized polypropylene construction ensures high reliability and self-extinguishing properties.
- Rated for 300V AC and 1.5 kV DC voltage withstand.
- Through hole mounting type with 15mm lead pitch and 25mm lead length.
- Complies with Y2/X1 safety classification as per IEC 60384-14 standard.
- Wide operating temperature range from -40°C to +125°C suitable for automotive applications.
- Qualified to meet demanding Automotive AEC-Q200 standards.
- Features low dissipation factor of 0.3% to minimize energy loss.
- Supplied in bag packaging ensuring protection during transport.
Product Description
KEMET R413I222050T1K is a high-quality metallized polypropylene film capacitor designed for electromagnetic interference (EMI) suppression in safety-critical line-to-ground and across-the-line filter applications. It offers a capacitance of 22 nanofarads with a tolerance of ±10%, making it suitable for precise filtering requirements. The capacitor is built to comply with IEC 60384-14 standards and carries Y2/X1 safety classification, ensuring reliable performance in harsh electrical environments.
This film capacitor supports a rated AC voltage of 300 volts and a rated DC voltage of 1.5 kilovolts, making it suitable for both AC and DC filtering applications. Its through-hole mounting facilitates secure soldering on printed circuit boards with a lead pitch of 15mm and lead length of 25mm. The capacitor is constructed with a self-extinguishing resin that meets UL94 V-0 flame rating, enhancing safety and durability.
The product operates efficiently across a wide temperature range from -40°C to +125°C, making it fully qualified to meet the AEC-Q200 automotive standard, suitable for automotive electronic systems and other demanding industrial uses. Its low dissipation factor of 0.3% reduces power losses for enhanced energy efficiency.
Physical dimensions include a length of 18mm, height of 12mm, and width of 6mm with lead diameter of 0.6mm, optimized for compact circuit designs. This capacitor is ideal for industrial, automotive, electronic manufacturing, and power supply filtering applications.
Metallized polypropylene construction with self-extinguishing resin. Safety classified as Y2/X1 according to IEC 60384-14 for EMI suppression. Rated for 300V AC and 1.5 kV DC with ±10% tolerance. Mounting: Through Hole with 15mm lead pitch and 25mm lead length.
Operating temperature: -40°C to +125°C compliant with Automotive AEC-Q200. Dimensions: 18mm (L) x 6mm (W) x 12mm (H), lead diameter 0.6mm. Low dissipation factor (0.3%) for energy efficiency. UL94 V-0 flame rating for safety.
Supplied in protective bag packaging. This Film Capacitor offers reliable filtering solutions in electronic components, power supplies, automotive electronics, and industrial machinery environments.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 22 nanofarads (nF).
It is rated for a maximum AC voltage of 300 volts (V AC).
The capacitor is rated for a maximum DC voltage of 1.5 kilovolts (kV DC).
The tolerance of this film capacitor is ±10%.
The dimensions are 18mm in length, 6mm in width, and 12mm in height, with a lead diameter of 0.6mm.
It uses a through-hole mounting type with a lead pitch of 15mm and a lead length of 25mm.
The operating temperature range is from -40°C to +125°C.
It complies with the Y2/X1 safety classification as per IEC 60384-14 standards.
The dissipation factor is 0.3%, which helps minimize energy loss.
Yes, it is qualified to meet the demanding Automotive AEC-Q200 standards, making it suitable for automotive electronic systems.
It is supplied in bag packaging to ensure protection during transport.
The country of origin for this capacitor is China.
