Omron E9C2-CWZ1X Rotary Encoder Current consumption-160 mA max.
Specifications
| Diameter | 50 MM |
|---|---|
| Applications | Servo Motor |
| Degree of Protection | IP64 |
| Current consumption | 160 mA max. |
| Ambient Operating Humidity | 35 to 85% RH (with no condensation) |
| Power Supply Voltage (V) | 5 VDC+-5% Ripple (p-p) 5% max. |
| Control Output Type | Line Driver Output |
| Connection Method | Pre-Wired Models (Cable length 2 m) |
| Ambient Operating Temperature | -10 to 70 Degree Celsius (with no icing) |
| Ambient Storage Temperature | -25 to 85 Degree Celsius (with no icing) |
| Categorise | Incremental Shaft Model |
| Control Output Voltage (V) | 2.5 V min. /0.5 V Max. |
Key Features
- Easy to use
- High efficiency
Product Description
Omron E9C2-CWZ1X Rotary Encoder (Current consumption-160 mA max.) is a transducer commonly used for measuring rotational motion. It consists of a shaft connected to a circular disc, containing one or more tracks of alternating transparent and opaque areas. A light source and an optical sensor are mounted on opposite sides of each track. they are inherently digital, which means they can interface easily to modern control systems. An encoder sends digital quality signals back to the computer.
- High durability
