Analog Devices High Speed Operational Amplifier 350 MHz Gain Bandwidth, Surface Mount SOIC 8-Pin 5V-12V AD8038ARZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Analog Devices |
| Height | 1.5mm |
| Length | 5mm |
| Model | AD8038ARZ |
| Width | 4mm |
| Mount Type | Surface |
| Series | Operational Amplifier |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 350MHz |
| Input Bias Current | 750 nA |
| Vos - Input Offset Voltage | 3 mV |
| Slew Rate | 365V/μs |
| Input Offset Current | 25 nA |
Key Features
- Operates with a supply voltage range from 5V to 12V for versatile power options.
- Features a gain bandwidth product of 350 MHz enabling high-frequency signal amplification.
- Compact 8-pin SOIC surface mount package facilitates easy PCB integration.
- High slew rate of 365 V/μs enables rapid signal transition for precise analog circuits.
- Wide operating temperature range from -40°C to 85°C ensures reliable performance in harsh environments.
- Low input offset voltage of 3 mV for accurate signal processing.
- Input bias current of 750 nA and input offset current of 25 nA minimize error currents.
- Package dimensions approximately 5mm length, 4mm width, and 1.5mm height for space-efficient design.
Product Description
Analog Devices AD8038ARZ is a high speed operational amplifier designed for applications requiring fast and accurate analog signal processing. Featuring a gain bandwidth product of 350 MHz, this device supports high-frequency operations in compact surface mount SOIC 8-pin packaging, making it ideal for dense circuit board layouts.
The amplifier operates over a wide supply voltage range from 5 V to 12 V and offers a high slew rate of 365 V/μs, enabling quick output voltage changes necessary for high-fidelity signal amplification. With an input offset voltage of 3 mV and low input bias and offset currents, the AD8038ARZ ensures precision in signal conditioning and measurement tasks.
This device is rated to work reliably in environments ranging from -40°C to 85°C, accommodating industrial, commercial, and laboratory applications. Its compact 5 mm by 4 mm package with 1.5 mm height facilitates seamless integration in modern electronic systems.
The AD8038ARZ is a single channel amplifier with an 8-pin configuration, making it suitable for a variety of amplification and signal processing uses, including instrumentation, control systems, and audio applications. It is not certified for automotive standards but well suited for general semiconductor amplifier needs.
Operates on 5V to 12V supply voltage range. 350 MHz gain bandwidth provides high-frequency performance. Compact SOIC 8-pin surface mount package. High slew rate of 365 V/μs for fast signal transitions. Wide temperature range support from -40°C to 85°C.
Low input offset voltage for precise amplification. Minimized input bias and offset currents. Package size optimized for space-saving circuit designs. Suitable for industrial, laboratory, and electronic system applications.
Single channel operation ideal for diverse usage scenarios.
This product is part of Analog Devices’ high-speed Operational Amplifier series, trusted for quality and performance in electronics manufacturing and development. Explore more options in the Electronics & Electricals category on EnvMart for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the AD8038ARZ is 350 MHz, enabling high-frequency signal amplification.
It operates with a supply voltage range from 5V to 12V, providing versatile power options for various applications.
The AD8038ARZ can operate in a temperature range from -40°C to 85°C, ensuring reliable performance in harsh environments.
This operational amplifier has dimensions of approximately 5 mm in length, 4 mm in width, and 1.5 mm in height.
The slew rate of this model is 365 V/μs, allowing for rapid signal transitions necessary for precise analog circuits.
This operational amplifier is a single channel device, making it suitable for various amplification tasks.
The input offset voltage of the AD8038ARZ is 3 mV, which helps ensure accurate signal processing.
The input bias current for this model is 750 nA, which minimizes error currents during operation.
It comes in a compact 8-pin SOIC surface mount package, facilitating easy PCB integration.
The input offset current of the AD8038ARZ is 25 nA, further contributing to its precision in signal conditioning.
This operational amplifier is suitable for applications in instrumentation, control systems, and audio processing.
The AD8038ARZ is manufactured in India, as indicated by its country of origin.
