Analog Devices Analogue Switch CMOS Single SPDT 8-Pin MSOP ADG719BRMZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Analog Devices |
| Height | 850μm |
| Length | 3mm |
| Model | ADG719BRMZ |
| Width | 3mm |
| Mount Type | Surface |
| Output type | CMOS/TTL |
| Series | ADG719 |
| Configuration | Single SPDT |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS |
| Minimum Supply Voltage | 1.8V |
| Maximum On State Resistance | 12Ω |
Key Features
- Operates with a single supply voltage range from 1.8V to 5.5V.
- Features low on-state resistance of 12 ohms to minimize signal loss.
- Supports high-speed switching with low distortion and leakage currents.
- Operational temperature range from -40°C to 125°C ensures reliability in various environments.
- Compact 3mm x 3mm MSOP package with 850μm height for efficient PCB layout.
- CMOS/TTL compatible output type compatible with a wide range of logic circuits.
- Surface mount type package suitable for automated assembly processes.
- Complies with RoHS standards, ensuring environmentally friendly manufacturing.
Product Description
Analog Devices ADG719BRMZ is a highly reliable analogue switch featuring a CMOS single SPDT configuration and packaged in an 8-pin MSOP form factor with dimensions of 3mm length, 3mm width, and 850μm height. This low power switch operates on a single supply voltage ranging from 1.8V to 5.5V and offers a low maximum on-state resistance of 12Ω, contributing to minimal signal attenuation and distortion during switching operations.
Designed for applications requiring high speed and precision switching, the device functions effectively over a wide temperature range from -40°C to 125°C, making it suitable for automotive and industrial electronics. Its CMOS/TTL output compatibility allows for interfacing with various digital logic families.
The MSOP surface mount package supports automated PCB assembly, enabling efficient manufacturing integration. This Analogue Switch supports multiple industrial applications including signal routing, multiplexing, and demultiplexing in electronic circuits. It complies with RoHS environmental standards, ensuring it meets global regulatory requirements.
Use cases include industrial instrumentation, communications equipment, consumer electronics, and automotive signal switching. The compact package size facilitates space-saving designs and high-density PCB layouts.
Operates from a single 1.8V to 5.5V power supply for versatile integration. Low on-resistance of 12Ω minimizes insertion losses in signal paths. Wide operating temperature range ensures performance in harsh conditions. Compact 8-pin MSOP surface mount package supports modern PCB designs.
CMOS/TTL output compatible for flexible interfacing. Surface mount package suitable for automated production lines. RoHS compliant for environmentally responsible manufacturing. Explore more Analog Devices semiconductor components and multiplexer ICs at EnvMart for your next electronics design project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a single supply voltage range from 1.8V to 5.5V.
The maximum on-state resistance is 12Ω, which helps minimize signal loss during operation.
It operates effectively over a temperature range from -40°C to 125°C, ensuring reliability in various environments.
This analogue switch features a CMOS/TTL output type, making it compatible with a wide range of digital logic circuits.
The package dimensions are 3mm in length, 3mm in width, and 850μm in height, suitable for compact PCB layouts.
It comes in an 8-pin MSOP package type and is designed for surface mount applications.
Yes, the ADG719BRMZ complies with RoHS standards, ensuring environmentally friendly manufacturing processes.
It supports multiple applications including signal routing, multiplexing, and demultiplexing in electronic circuits.
This chip contains 1 element per chip, designed for single SPDT configurations.
The device is compatible with the CMOS logic family, allowing for flexible interfacing with various digital circuits.
The low on-state resistance of 12Ω minimizes insertion losses in signal paths, enhancing performance during switching operations.
Typical use cases include industrial instrumentation, communications equipment, consumer electronics, and automotive signal switching.
