Texas Instruments Timer Circuit 1 Internal Timer, 8-Pin SOIC, 4.5V-18V Operating Voltage NE555DR

Texas Instruments NE555DR is a precision timer circuit featuring 1 internal timer, housed in an 8-Pin SOIC package. It supports a wide operating voltage range from 4.5V up to 18V, ensuring flexibility for diverse electronic applications.

This timer integrates reliably within temperature conditions from 0°C to 70°C, making it suitable for standard industrial and laboratory environments. With a compact length of 5mm and height of 1.75mm, it fits well into high-density circuit boards that require through-hole mounting solutions.

The NE555DR model features a propagation delay test condition with a 15pF external capacitance, enhancing timing accuracy necessary for precision electronic timers and clocks. Although it lacks specific automotive approvals, its robust design is tailored for consumer electronics, instrumentation, and prototyping usage.

This device finds extensive application in industrial automation, electronic instrumentation, and control systems where precise timing intervals are vital. It is ideal for timer circuits, pulse generation, oscillator, and sequential timing applications.

The timer circuit's reliability and adaptability make it a staple in semiconductor components for designers and engineers seeking a trusted timing IC solution. Integrated 1 internal timer for precise timing applications.

Compact 8-pin SOIC package suitable for through-hole mounting. Operates reliably within 0 to 70°C temperature range. Voltage supply range from minimum 4.5V to maximum 18V. Length of 5mm and height of 1.75mm to fit compact circuit designs.

Propagation delay tested at 15pF capacitance for accurate timing. Does not conform to automotive standards, designed for general electronic use. Compatible with various clock, timing, and frequency circuit applications. Explore more semiconductor and Timer Circuit solutions on EnvMart to suit your project needs.
